Command List
FCB-EH6500(GB) A-EEP-100-11(1)
Exposure control (2/2)
Iris Gain
Bright
1F F1.8
43.5 dB
(28 step)
1E F1.8
40.4 dB
(26 step)
1D F1.8
37.3 dB
(24 step)
1C F1.8
34.2 dB
(22 step)
1B F1.8
31.1 dB
(20 step)
1A F1.8
28.0 dB
(18 step)
19 F1.8
24.9 dB
(16 step)
18 F1.8
21.8 dB
(14 step)
17 F1.8
18.6 dB
(12 step)
16 F1.8
15.5 dB
(10 step)
15 F1.8
12.4 dB
(8 step)
14 F1.8
9.3 dB
(6 step)
13 F1.8
6.2 dB
(4 step)
12 F1.8
3.1 dB
(2 step)
11 F1.8
0 dB
(0 step)
10 F2
0 dB
(0 step)
0F F2.4
0 dB
(0 step)
0E F2.8
0 dB
(0 step)
0D F3.4
0 dB
(0 step)
0C F4
0 dB
(0 step)
0B F4.8
0 dB
(0 step)
0A F5.6
0 dB
(0 step)
09 F6.8
0 dB
(0 step)
08 F8
0 dB
(0 step)
07 F9.6
0 dB
(0 step)
00 CLOSE
0 dB
(0 step)
Exposure Comp.
0E +7 +10.5 dB
0D +6 +9 dB
0C +5 +7.5 dB
0B +4 +6 dB
0A +3 +4.5 dB
09 +2 +3 dB
08 +1 +1.5 dB
07 0 0 dB
06 −1 −1.5 dB
05 −2 −3 dB
04 −3 −4.5 dB
03 −4 −6 dB
02 −5 −7.5 dB
01 −6 −9 dB
00 −7 −10.5 dB
Zoom Ratio and Zoom Position
(for reference)
Optical Zoom Ratio
Optical Zoom
Position Data
1× 0000
2× 17C5
3× 22AD
4× 2990
5× 2EAF
6× 32EC
7× 36B4
8× 3A32
9× 3D5B
10× 4000
Digital Zoom Combine mode
Digital Zoom
Ratio
Digital Zoom
Position Data
1× 4000
2× 6000
3× 6A80
4× 7000
5× 7300
6× 7540
7× 76C0
8× 7800
9× 78C0
10× 7980
11× 7A00
12× 7AC0
Digital Zoom Separate mode
Digital Zoom
Ratio
Digital Zoom
Position Data
1× 00
2× 80
3× AA
4× C0
5× CC
6× D5
7× DB
8× E0
9× E3
10× E6
11× E8
12× EB
