54
Command List
FCB-EH6500(GB) A-EEP-100-11(1)
Lens control
Zoom Position
0000 to 4000 to 7AC0
Wide end Optical Digital
Tele end Tele end
Focus Position
1000 to F000
Far end Near end
Focus Near
Limit
1000: Over Inf
2000: 4.0 m
3000: 2.0 m
4000: 1.2 m
5000: 80 cm
6000: 50 cm
7000: 32 cm
(initial setting)
8000: 19 cm
9000: 12 cm
A000: 8.0 cm
B000: 5.2 cm
C000: 3.4 cm
D000 : 2.2 cm
E000: 1.5 cm
F000: 1 cm
As the distance on the left
will differ due to temperature
characteristics, etc., use as
approximate values.
* The lower 1 byte is fixed at 00.
Wide/Tele Limit Setting
Wide/Tele Limit
Setting Value
Wide Limit Tele Limit
Limit Setting
Value
Zoom
Position
Zoom
Ratio
Zoom
Position
Zoom
Ratio
00 0000 1 4000 10
10 00F4 1.02 3F0B 9.61
20 01E9 1.04 3E16 9.25
30 02DD 1.07 3D22 8.92
40 03D2 1.10 3C2D 8.60
50 04C6 1.13 3B39 8.31
60 05BB 1.15 3A44 8.01
70 06B0 1.18 394F 7.73
80 07A4 1.22 385B 7.46
90 0899 1.25 3766 7.19
A0 098D 1.28 3372 6.92
B0 0A82 1.32 357D 6.66
C0 0B77 1.35 3488 6.41
D0 0C6B 1.39 3394 6.16
E0 0D60 1.43 329F 5.92
F0 0E54 1.47 31AB 5.68
FF 0F3A 1.51 30C5 5.47
Temperature Reading Conversion Value
(Reference Value)
Reading Value
pq (hex)
Temperature
Conversion
Value (ºC)
FB −8 to −2
00 −3 to +3
0A 7 to 13
14 17 to 23
1E 27 to 33
28 37 to 43
32 47 to 53
3C 57 to 63
