Sony FCB-EV7100 - Register Settings

55
Command List
FCB-EH6500(GB) A-EEP-100-11(1)
Register Setting
The register settings are enabled when the power is
turned off and then back on again. After turning the
power back on again, verify that the mode settings have
been changed.
Register No. Value
VISCA
Baud Rate
00 00
(Initial setting)
9600 bps
01 19200 bps
02 38400 bps
03 115200 bps
Monitoring
Mode
72 01
(Initial setting)
1080i/59.94
02 1080i/60
03 NTSC Analog Output
(Stop Digital Output)
04 1080i/50
05 PAL Analog Output
(Stop Digital Output)
06 1080p/29.97
07 1080p/30
08 1080p/25
09 720p/59.94
0A 720p/60
0B Reserved
0C 720p/50
0D Reserved
0E 720p/29.97
0F 720p/30
10 Reserved
11 720p/25
12 Reserved
13 1080p/59.94
14 1080p/50
15 1080p/60
Output
Enabling
73 01 Analog Output
enabled
02 Digital Output
enabled
03
(Initial setting)
Both Analog/Digital
Output enabled
LVDS Mode
74 00
(Initial setting)
Single output
01 Double output
Low Delay
Mode
(Supported in
FW ver. 2.00 or
later)
75 00
(Initial setting)
Normal Mode
01 Low Delay Mode
Zoom Limit
50 00-FF
(Initial setting: 00)
Wide Limit
(0: Disabled)
51 00-FF
(Initial setting: 00)
Tele Limit
(0: Disabled)
D-Zoom Max
52 00-EB
(Initial setting: EB)
Max. digital
zoom ratio =
256 ÷ (256-Value)
“StableZoom” 53 00
(Iinitial Setting: 00)
Off
01 On
Register No. Value
FocusTrace
@ZoomDirect
54 00 Off
01
(Iinitial Setting: 01)
On
FocusOffset
@DomeCover
55 00-FF
(Iinitial Setting: 00)
00: None to
FF: Max.
AE Parameter
Change During
VE On, Defog
On
(Supported in
FW ver. 2.00 or
later)
58 00 OFF
01
(Iinitial Setting)
ON
Auto Slow
Shutter Limit
(Supported in
FW ver. 2.00 or
later)
59 01 1/30
02 1/15
03 1/8
04
(Iinitial Setting)
1/4
05 1/2
06 1/1
Extended
Normal Shutter
(Supported in
FW ver. 2.00 or
later)
5A 00
(Iinitial Setting)
OFF
01 Allowed up to
1/30
02 Allowed up to
1/15
03 Allowed up to
1/8
04 Allowed up to
1/4
05 Allowed up to
1/2
06 Allowed up to
1/1
Defog Limit
(Supported in
FW ver. 3.00 or
later)
5B 00-FF
(Iinitial Setting: FF)
Defog level
Low Limit
5C 00-FF
(Iinitial Setting: FF)
Defog level
Mid Limit
5D 00-FF
(Iinitial Setting: FF)
Defog level
High Limit
Extended
Mode
5F 00
(Iinitial Setting)
OFF
bit: 0 Exposure compensation
Extended 256 levels On/Off
bit: 1 Aperture Extended 256 levels
On/Off
bit: 2 Color Gain/Hue Extended 256
levels On/Off
bit: 3 Auto ICR Off  On setting
enable On/Off
*For all of bit, 1 is to activate, 0 is
Off
