Command List
FCB-EH6500(GB) A-EEP-100-11(1)
40
Command List (5/6)
Command Set Command Command Packet Comments
CAM_IDWrite — 8x 01 04 22 0p 0q 0r 0s FF pqrs: Camera ID (=0000h to FFFFh)
CAM_MD On 8x 01 04 1B 02 FF MD On/Off
Off 8x 01 04 1B 03 FF
Function Set 8x 01 04 1C 0m 0n 0p 0q 0r 0s FF m: Display mode
n: Detection Frame Set (00h to 0Fh)
pq: Threshold Level (00h to FFh)
rs: Interval Time set (00h to FFh)
Window Set 8x 01 04 1D 0m 0p 0q 0r 0s FF m: Select Detection Frame (0, 1, 2, 3)
p: Start Horizontal Position (00h to 0Fh)
q: Start Vertical Position (00h to 07h)
r: Stop Horizontal Position (01h to 10h)
s: Stop Vertical Position (01h to 08h)
Alarm (Reply) y0 07 04 1B 0p FF p: Detection Frame Number
CAM_Continuous
ZoomPosReply
On 8x 01 04 69 02 FF Zoom Position data Continuous Output On/Off
Off 8x 01 04 69 03 FF
(Reply) y0 07 04 69 0p 0p 0q 0q 0q 0q FF pp: D-Zoom Position
* 00: When Zoom Mode is Combine
qqqq: Zoom Position
CAM_ZoomPos
ReplyIntervalTimeSet
— 8x 01 04 6A 00 00 0p 0p FF pp: Interval Time [V cycle]
CAM_Continuous
FocusPosReply
On 8x 01 04 16 02 FF Focus Position data Continuous Output On/Off
Off 8x 01 04 16 03 FF
(Reply) y0 07 04 16 00 00 0p 0p 0p 0p FF pppp: Focus Position
CAM_FocusPosReply
IntervalTimeSet
— 8x 01 04 1A 00 00 0p 0p FF pp: Interval Time [V cycle]
CAM_RegisterValue — 8x 01 04 24 mm 0p 0p FF mm: Register No. (=00h to 7Fh)
pp: Register Value (=00h to FFh)
CAM_ColorEnhance Parameter Set 8x 01 04 20 mm 00 pp
qq rr ss tt uu FF
mm: Threshold level
pp: Y fixed color for high-intensity
qq: Cr fixed color for high-intensity
rr: Cb fixed color for high-intensity
ss: Y fixed color for low-intensity
tt: Cr fixed color for low-intensity
uu: Cb fixed color for low-intensity
Each parameter setting 00h to 7Fh
On 8x 01 04 50 02 FF Color Enhancement On/Off
Off 8x 01 04 50 03 FF
CAM_ChromaSuppress — 8x 01 04 5F pp FF pp: Chroma Suppress setting level
00: Off
01h to 03h: On (3 levels).
Effect increases as the level number increases.
CAM_ColorGain Direct 8x 01 04 49 00 00 00 0p FF p: Color Gain Setting 0h (60%) to Eh (200%)
CAM_ColorHue Direct 8x 01 04 4F 00 00 00 0p FF p: Color Hue Setting 0h (-14 degrees) to Eh (+14 degrees)
CAM_GammaOffset Direct 8x 01 04 1E 00 00 00 0s 0t 0u FF s: Polarity offset (0 is plus, 1 is minus)
tu: Offset s=0 (00h to 40h)
Offset s=1 (00h to 10h)
