5
PIN ASSIGNMENT
n 4-pin for Y/C Video Out
Pin No. Name Level
1 Y_OUT 1.0 Vp-p (75 Ω terminate) Luminance signal
2 GND (for Y signal) –
3 C_OUT Chrominance signal
4 GND (for C signal) –
Connector: JST S4B-ZR-SM4A-TF (LF)
Pin No. Name Level
1 RxD CMOS 5.0 V (Low: max 0.8 V, High: min 2.0 V) Read Data
2 TxD CMOS 5.0 V (Low: max 0.1 V, High: min 4.4 V) Send Data
3 GND (for RxD & TxD) –
4 DC IN 9.0 V ±3.0 V
5 GND (for DC IN) –
6 VBS OUT 1.0 Vp-p (75 Ω terminate)
7 GND (for VBS OUT) –
8 V LOCK PULSE External VD-Lock Pulse (Negative, 3.0 Vp-p 50% duty)
9 GND (for V LOCK PULSE) –
n 9-pin for DC/Video Out
Pin No. Name Level
1 GND –
2 GND –
3 KEY_AD0 Pull up to 3.0 V by 100 kΩ
4 KEY_AD1 Pull up to 3.0 V by 100 kΩ
5 KEY_AD2 Pull up to 3.0 V by 100 kΩ
6 KEY_AD3 Pull up to 3.0 V by 100 kΩ
7 KEY_AD4 Pull up to 3.0 V by 100 kΩ
8 KEY_AD5 Pull up to 3.0 V by 100 kΩ
9 KEY_AD6 Pull up to 3.0 V by 100 kΩ
10 KEY_AD7 Pull up to 3.0 V by 100 kΩ
11 NC –
12 Strobe Strobe timing pulse (0 to 3.0 V)
Connector: KYOCERA ELCO 08 6222 012 101 848+
n 12-pin for Key Switch Control
Pin No. Name Level
1 GND
2 Digital Out 0 0 - 3.3 Vp-p
3 Digital Out 1 0 - 3.3 Vp-p
4 Digital Out 2 0 - 3.3 Vp-p
5 Digital Out 3 0 - 3.3 Vp-p
6 Digital Out 4 0 - 3.3 Vp-p
7 Digital Out 5 0 - 3.3 Vp-p
8 Digital Out 6 0 - 3.3 Vp-p
9 Digital Out 7 0 - 3.3 Vp-p
10 GND
11 CLOCK 0 - 3.3 Vp-p
12 GND
CN500 FCB-EX1020/FCB-EX1020P
FCB-EX995E/FCB-EX995EP
FCB-EX985E/FCB-EX985EP
FCB-EX490E/FCB-EX490EP
FCB-EX48E/FCB-EX48EP
CN602 FCB-EX20D/FCB-EX20DP
CN402 FCB-EX11D/FCB-EX11DP
CN601 FCB-EX20D/FCB-EX20DP
CN401 FCB-EX11D/FCB-EX11DP
CN501 FCB-EX1020/FCB-EX1020P
FCB-EX995E/FCB-EX995EP
FCB-EX985E/FCB-EX985EP
FCB-EX490E/FCB-EX490EP
FCB-EX48E/FCB-EX48EP
FCB-EX15E/FCB-EX15EP
FCB-EX12E/FCB-EX12EP
CN702 FCB-EX1020/FCB-EX1020P
FCB-EX995E/FCB-EX995EP
FCB-EX985E/FCB-EX985EP
FCB-EX490E/FCB-EX490EP
FCB-EX48E/FCB-EX48EP
CN801 FCB-EX20D/FCB-EX20DP
Connector: KYOCERA ELCO 00 6200 509 130 000+
n 12-pin for Digital Out
CN200 FCB-EX1020/FCB-EX1020P
FCB-EX995E/FCB-EX995EP
FCB-EX985E/FCB-EX985EP
FCB-EX490E/FCB-EX490EP
FCB-EX48E/FCB-EX48EP
Connector: KYOCERA ELCO 08 6222 012 101 848+ [FFC 0.5 mm Pitch]
Pin No. Name Level
1 TXOUT3+
2 TXOUT3-
3 TXCLKOUT+
4 TXCLKOUT-
5 TXOUT2+
6 TXOUT2-
7 TXOUT1+
8 TXOUT1-
9 TXOUT0+
10 TXOUT0-
11 GND
12 TxD CMOS 5 V (Low: Max. 0.1 V, High: Min. 4.4 V)
13 RxD CMOS 5 V (Low: Max. 0.8 V, High: Min. 2.0 V)
14 DC IN 6 to 12 V DC
15 DC IN 6 to 12 V DC
16 DC IN 6 to 12 V DC
17 DC IN 6 to 12 V DC
18 DC IN 6 to 12 V DC
19 GND
20 GND
21 GND
22 GND
23 GND
24 GND
25 GND
26 GND
27 VBS OUT
28 GND
29 V LOCK PULSE
30 GND
Connector: USL00-30L-C (KEL Corp.)
n 30-pin for Digital Out
CN601 FCB-EX15E/FCB-EX15EP
FCB-EX12E/FCB-EX12EP
