Sony FCB-H11 - Exposure Control (2;2)

34
Command List
Exposure Control (2/2)
IRIS GAIN
Bright 17 F1.8 18 dB
16 F1.8 15 dB
15 F1.8 12 dB
14 F1.8 9 dB
13 F1.8 6 dB
12 F1.8 3 dB
11 F1.8 0 dB
10 F2.0 0 dB
0F F2.4 0 dB
0E F2.8 0 dB
0D F3.4 0 dB
0C F4.0 0 dB
0B F4.8 0 dB
0A F5.6 0 dB
09 F6.8 0 dB
08 F8.0 0 dB
07 F9.6 0 dB
06 F11 0 dB
05 F14 0 dB
04 F16 0 dB
03 F19 0 dB
02 F22 0 dB
01 F26 0 dB
00 CLOSE 0 dB
Zoom Ratio and Zoom Position
(for HD reference)
Zoom Ratio Position Data D-Zoom
Ratio
×1 0000
×1.2 0800
1.5 1000
×1.9 1800
×2.5 2000
×3.4 2800
×4.8 3000
×6.8 3800
×10.1 4000
4000 ×1
5bc0 ×1.5
69c0 ×2
7e80 ×4
8900 ×8
8c40 ×12
Focus and Focus Distance (for HD
reference)
Focus Position
1000: Over Inf to C000: 1.0 cm
Far end Near end
1000: Over Inf. As the distance on the left
2000: 4.5 m will differ due to
3000: 2.0 m temperature characteristics,
Focus Near 4000:1.2 m etc., use as approximate
Limit 5000: 80 cm values.
6000: 45 cm *The lower 1 byte is fixed
7000: 38 cm at 00.
8000: 15 cm
9000: 7.0 cm
A000: 3.8 cm
B000: 2.1 cm
C000: 1.0 cm
Step GAIN
Exposure Comp. 0E +7 +10.5 dB
0D +6 +9 dB
0C +5 +7.5 dB
0B +4 +6 dB
0A +3 +4.5 dB
09 +2 +3 dB
08 +1 +1.5 dB
07 0 0 dB
06 –1 –1.5 dB
05 –2 –3 dB
04 –3 –4.5 dB
03 –4 –6 dB
02 –5 –7.5 dB
01 –6 –9 dB
00 –7 –10.5 dB
