112
REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
D
D6808 8-719-510-73 DIODE S3L20UF4
D6809 8-719-991-33 DIODE 1SS133T-77
D6810 1-247-895-91 CARBON 470K 5% 1/4W
D6811 8-719-110-41 DIODE MTZJ-T-77-15B
D6851 8-719-970-87 DIODE ERA38-06TP1
D6852 8-719-970-87 DIODE ERA38-06TP1
< FERRITE BEAD >
FB6602 1-410-396-41 FERRITE 0.45UH
FB6603 1-410-396-41 FERRITE 0.45UH
< IC >
IC6600 1-810-051-11 POWER MODULE DM-48
IC6604 8-729-045-40 TRANSISTOR MX0842A-F
IC6651 8-759-468-89 IC TOP209P
IC6652 8-759-394-35 IC BA12T
IC6653 8-759-054-12 IC PQ09RFU
IC6654 8-759-574-76 IC KA78R05-SYDTU
IC6667 8-759-908-15 IC TL431CZ
IC6676 8-759-908-15 IC TL431CZ
IC6700 8-759-192-71 IC STV9379
IC6801 8-759-103-93 IC LM393P
< COIL >
L6602 1-412-529-11 INDUCTOR 22UH
L6603 1-412-529-11 INDUCTOR 22UH
L6604 1-412-525-31 INDUCTOR 10UH
L6605 1-412-523-41 INDUCTOR 6.8UH
L6606 1-412-525-31 INDUCTOR 10UH
L6607 1-412-525-31 INDUCTOR 10UH
L6651 1-414-183-41 INDUCTOR 10UH
L6700 1-412-524-11 INDUCTOR 8.2UH
L6801 1-412-519-11 INDUCTOR 3.3UH
L6802 1-412-519-11 INDUCTOR 3.3UH
L6803 1-412-533-21 INDUCTOR 47UH
L6805 1-408-947-00 INDUCTOR 2.2MH
L6806 1-535-143-61 LEAD, JUMPER (5.0MM)
L6807 1-410-397-21 FERRITE 1.1UH
L6851 1-535-143-61 LEAD JUMPER (5.0MM)
< FILTER >
LF6603 1-406-659-11 INDUCTOR 10UH
LF6604 1-406-659-11 INDUCTOR 10UH
LF6801 1-406-985-11 INDUCTOR 2.2MH
LF6851 1-406-674-11 INDUCTOR 3.3MH
< IC LINK >
PS6601 £ 1-801-550-21 PROTECTOR, MODULE 2.5A MP250
PS6602 £ 1-801-550-21 PROTECTOR, MODULE 2.5A MP250
PS6603 £ 1-801-549-21 PROTECTOR, MODULE 4.0A MP250
PS6604 £ 1-801-550-21 PROTECTOR, MODULE 2.5A MP250
PS6605 £ 1-801-550-21 PROTECTOR, MODULE 2.5A MP250
< TRANSISTOR >
Q6600 £ 8-729-046-47 TRANSISTOR KSC2500-BTA
Q6602 8-729-026-39 TRANSISTOR 2SA933AS-RT
Q6603 8-729-119-78 TRANSISTOR 2SC1740S-RT
Q6605 8-729-046-47 TRANSISTOR KSC2500-BTA
Q6606 8-729-029-56 TRANSISTOR DTA144ESA-TP
Q6607 8-729-119-78 TRANSISTOR 2SC1740S-RT
Q6608 8-729-029-66 TRANSISTOR DTC114ESA-TP
Q6611 8-729-029-66 TRANSISTOR DTC114ESA-TP
Q6651 8-729-026-39 TRANSISTOR 2SA933AS-RT
Q6652 8-729-029-86 TRANSISTOR DTC124ESA-TP
Q6667 8-729-026-39 TRANSISTOR 2SA933AS-RT
Q6676 8-729-119-78 TRANSISTOR 2SC1740S-RT
Q6677 8-729-119-78 TRANSISTOR 2SC1740S-RT
Q6678 8-729-119-78 TRANSISTOR 2SC1740S-RT
Q6679 8-729-026-39 TRANSISTOR 2SA933AS-RT
Q6680 8-729-029-66 TRANSISTOR DTC114ESA-TP
Q6681 8-729-029-66 TRANSISTOR DTC114ESA-TP
Q6700 8-729-039-68 TRANSISTOR IRF620
Q6801 8-729-119-80 TRANSISTOR 2SC2688-LK
Q6802 8-729-119-80 TRANSISTOR 2SC2688-LK
Q6803 8-729-046-18 TRANSISTOR 2SC5480-01
Q6804 8-729-046-18 TRANSISTOR 2SC5480-01
Q6805 8-729-038-83 TRANSISTOR 2SK2251-01-F19
Q6806 8-729-047-59 TRANSISTOR STP5NB40FP
Q6807 8-729-030-02 TRANSISTOR DTC144ESA-TP
Q6851 8-729-043-95 TRANSISTOR 2SC3840K
< RESISTOR >
R6601 £ 1-202-968-11 CEMENTED 1.2 5% 10W
R6602 1-249-433-11 CARBON 22K 5% 1/4W
R6603 £ 1-249-430-11 CARBON 12K 5% 1/4W
R6604 £ 1-249-421-11 CARBON 2.2K 5% 1/4W
R6605 1-249-417-11 CARBON 1K 5% 1/4W
R6606 £ 1-202-968-11 CEMENTED 1.2 5% 10W
R6608 £ 1-220-797-11 CEMENTED 0.47 5% 10W
R6611 1-260-125-11 CARBON 150K 5% 1/2W
R6612 1-260-125-11 CARBON 150K 5% 1/2W
R6613 1-216-369-00 METAL OXIDE 1 5% 2W
To Next Page
