114
REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
*A-1651-137-A J Board, Complete
JD
R6837 1-215-919-11 METAL OXIDE 2.2K 5% 3W
R6838 1-214-905-11 METAL 47K 1% 1/2W
R6839 1-215-919-11 METAL OXIDE 2.2K 5% 3W
R6840 1-247-843-11 CARBON 3.3K 5% 1/4W
R6842 1-260-123-11 CARBON 100K 5% 1/2W
R6843 1-249-429-11 CARBON 10K 5% 1/4W
R6844 1-249-441-11 CARBON 100K 5% 1/4W
R6845 1-249-433-11 CARBON 22K 5% 1/4W
R6851 1-260-123-11 CARBON 100K 5% 1/2W
R6852 1-260-123-11 CARBON 100K 5% 1/2W
R6853 1-260-123-11 CARBON 100K 5% 1/2W
R6854 1-249-417-11 CARBON 1K 5% 1/4W
R6856 1-216-485-11 METAL OXIDE 5.6K 5% 3W
R6857 1-216-485-11 METAL OXIDE 5.6K 5% 3W
R6858 1-215-922-11 METAL OXIDE 6.8K 5% 3W
R6859 1-215-922-11 METAL OXIDE 6.8K 5% 3W
R6880 1-215-436-00 METAL 4.3K 1% 1/4W
R6885 1-215-493-00 METAL 1M 1% 1/4W
R6886 1-215-477-00 METAL 220K 1% 1/4W
R6887 1-215-461-00 METAL 47K 1% 1/4W
R6888 1-249-441-11 CARBON 100K 5% 1/4W
R6891 1-535-143-61 LEAD, JUMPER (5.0MM)
R6892 1-535-143-61 LEAD, JUMPER (5.0MM)
R6895 1-249-443-11 CARBON 0.47 5% 1/4W
R6896 1-249-443-11 CARBON 0.47 5% 1/4W
R6897 1-215-485-00 METAL 470K 1% 1/4W
R6898 1-215-493-00 METAL 1M 1% 1/4W
R6899 1-215-493-00 METAL 1M 1% 1/4W
< RELAY >
RY6601 £ 1-755-266-11 RELAY, AC POWER
RY6602 £ 1-755-167-11 RELAY, AC POWER
< TRANSFORMER >
T6600 £ 1-431-616-11 TRANSFORMER, CONVERTER
T6601 £ 1-433-516-11 TRANSFORMER, CONVERTER (PIT)
T6651 1-431-732-21 TRANSFORMER, CONVERTER (SRT)
T6801 1-433-489-11 TRANSFORMER, FERRITE (HDT)
T6802 1-433-489-11 TRANSFORMER, FERRITE (HDT)
T6804 £ 1-453-340-11 TRANSFORMER ASSY, FLYBACK (NX4522//U214)
T6852 1-433-487-11 TRANSFORMER, FERRITE (DFT)
< THERMISTOR >
TH6600 £ 1-809-827-11 THERMISTOR, POSITIVE
TH6700 1-800-193-00 THERMISTOR
< CAPACITOR >
C8105 1-126-933-11 ELECT 100UF 20.00% 16V
C8106 1-126-933-11 ELECT 100UF 20.00% 16V
C8107 1-126-935-11 ELECT 470UF 20.00% 16V
C8108 1-126-933-11 ELECT 100UF 20.00% 16V
C8109 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C8110 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C8111 1-126-933-11 ELECT 100UF 20.00% 16V
C8112 1-107-715-11 ELECT 22UF 20.00% 16V
C8144 1-107-823-11 CERAMIC CHIP 0.47UF 10.00% 16V
C8145 1-107-823-11 CERAMIC CHIP 0.47UF 10.00% 16V
C8200 1-104-664-11 ELECT 47UF 20.00% 16V
C8201 1-163-241-11 CERAMIC CHIP 39PF 5.00% 50V
C8202 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C8203 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C8204 1-164-506-11 CERAMIC CHIP 4.7UF 16V
C8205 1-165-319-11 CERAMIC CHIP 0.1UF 50V
C8208 1-164-506-11 CERAMIC CHIP 4.7UF 16V
C8209 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C8210 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C8211 1-163-243-11 CERAMIC CHIP 47PF 5.00% 50V
C8212 1-163-243-11 CERAMIC CHIP 47PF 5.00% 50V
C8213 1-163-087-00 CERAMIC CHIP 4PF 0.25PF 50V
C8214 1-163-087-00 CERAMIC CHIP 4PF 0.25PF 50V
C8215 1-163-243-11 CERAMIC CHIP 47PF 5.00% 50V
C8216 1-126-933-11 ELECT 100UF 20.00% 16V
C8217 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C8218 1-126-964-11 ELECT 10UF 20.00% 50V
C8219 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C8220 1-126-964-11 ELECT 10UF 20.00% 50V
C8221 1-104-664-11 ELECT 47UF 20.00% 16V
C8222 1-104-664-11 ELECT 47UF 20.00% 16V
C8223 1-104-664-11 ELECT 47UF 20.00% 16V
C8224 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C8225 1-104-664-11 ELECT 47UF 20.00% 16V
C8227 1-163-009-11 CERAMIC CHIP 0.001UF 10.00% 50V
C8228 1-163-009-11 CERAMIC CHIP 0.001UF 10.00% 50V
C8229 1-163-009-11 CERAMIC CHIP 0.001UF 10.00% 50V
C8230 1-163-009-11 CERAMIC CHIP 0.001UF 10.00% 50V
C8231 1-163-009-11 CERAMIC CHIP 0.001UF 10.00% 50V
C8232 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C8233 1-104-664-11 ELECT 47UF 20.00% 16V
C8234 1-107-823-11 CERAMIC CHIP 0.47UF 10.00% 16V
C8235 1-107-823-11 CERAMIC CHIP 0.47UF 10.00% 16V
C8236 1-126-933-11 ELECT 100UF 20.00% 16V
