116
REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
C8868 1-126-964-11 ELECT 10UF 20.00% 50V
C8869 1-164-004-11 CERAMIC CHIP 0.1UF 10.00% 25V
C8896 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C8897 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C8898 1-163-227-11 CERAMIC CHIP 10PF 0.50PF 50V
C8899 1-163-227-11 CERAMIC CHIP 10PF 0.50PF 50V
C8900 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C8901 1-163-017-00 CERAMIC CHIP 0.0047UF 10.00% 50V
C8902 1-163-017-00 CERAMIC CHIP 0.0047UF 10.00% 50V
C8903 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C8904 1-163-017-00 CERAMIC CHIP 0.0047UF 10.00% 50V
C8905 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C8906 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C8907 1-163-017-00 CERAMIC CHIP 0.0047UF 10.00% 50V
C8908 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C8909 1-163-017-00 CERAMIC CHIP 0.0047UF 10.00% 50V
C8910 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C8911 1-163-017-00 CERAMIC CHIP 0.0047UF 10.00% 50V
C8914 1-126-933-11 ELECT 100UF 20.00% 16V
C8977 1-163-009-11 CERAMIC CHIP 0.001UF 10.00% 50V
C8978 1-163-009-11 CERAMIC CHIP 0.001UF 10.00% 50V
< FILTER >
CF8200 1-409-327-00 TRAP, CERAMIC (6.5MHZ)
< CONNECTOR >
CN8101 1-695-302-11 CONNECTOR, BOARD TO BOARD 50P
CN8900 1-561-534-41 SOCKET, PIN 21P
CN8901 1-695-293-11 SOCKET 21P
CN8902 1-695-293-11 SOCKET 21P
< DIODE >
D8153 8-719-056-83 DIODE UDZ-TE-17-6.8B
D8200 8-719-158-49 DIODE UDZ-TE-17-12B
D8201 8-719-158-49 DIODE UDZ-TE-17-12B
D8202 8-719-158-49 DIODE UDZ-TE-17-12B
D8203 8-719-158-49 DIODE UDZ-TE-17-12B
D8801 8-719-158-49 DIODE UDZ-TE-17-12B
D8802 8-719-158-49 DIODE UDZ-TE-17-12B
D8803 8-719-158-49 DIODE UDZ-TE-17-12B
D8804 8-719-158-49 DIODE UDZ-TE-17-12B
D8805 8-719-158-49 DIODE UDZ-TE-17-12B
D8806 8-719-158-49 DIODE UDZ-TE-17-12B
D8807 8-719-158-49 DIODE UDZ-TE-17-12B
D8808 8-719-158-49 DIODE UDZ-TE-17-12B
D8809 8-719-158-49 DIODE UDZ-TE-17-12B
D8810 8-719-158-49 DIODE UDZ-TE-17-12B
D8811 8-719-158-49 DIODE UDZ-TE-17-12B
D8812 8-719-158-49 DIODE UDZ-TE-17-12B
D8813 8-719-158-49 DIODE UDZ-TE-17-12B
D8814 8-719-158-49 DIODE UDZ-TE-17-12B
D8900 8-719-056-85 DIODE UDZS-TE-17-8.2B
D8901 8-719-158-49 DIODE UDZ-TE-17-12B
D8902 8-719-056-85 DIODE UDZS-TE-17-8.2B
D8903 8-719-056-85 DIODE UDZS-TE-17-8.2B
D8904 8-719-056-85 DIODE UDZS-TE-17-8.2B
D8905 8-719-056-85 DIODE UDZS-TE-17-8.2B
D8906 8-719-056-85 DIODE UDZS-TE-17-8.2B
D8907 8-719-158-49 DIODE UDZ-TE-17-12B
D8908 8-719-056-85 DIODE UDZS-TE-17-8.2B
D8909 8-719-056-85 DIODE UDZS-TE-17-8.2B
D8910 8-719-056-85 DIODE UDZS-TE-17-8.2B
D8911 8-719-056-85 DIODE UDZS-TE-17-8.2B
D8912 8-719-158-49 DIODE UDZ-TE-17-12B
D8913 8-719-158-49 DIODE UDZ-TE-17-12B
D8914 8-719-158-49 DIODE UDZ-TE-17-12B
D8915 8-719-158-49 DIODE UDZ-TE-17-12B
< FILTER >
FL8200 1-236-071-11 ENCAPSULATED COMPONENT
FL8201 1-233-764-21 FILTER
FL8203 1-236-071-11 ENCAPSULATED COMPONENT
FL8302 1-236-071-11 ENCAPSULATED COMPONENT
FL8304 1-236-071-11 ENCAPSULATED COMPONENT
FL8308 1-236-071-11 ENCAPSULATED COMPONENT
FL8801 1-236-071-11 ENCAPSULATED COMPONENT
FL8802 1-236-071-11 ENCAPSULATED COMPONENT
< IC >
IC8101 8-759-576-76 IC TDA2822D013TR
IC8151 8-752-072-94 IC CXA1875AM-T4
IC8200 8-759-654-42 IC MSP3410D-C5QA-B4
IC8201 8-759-701-36 IC MC3403NS-E20
IC8202 8-759-908-15 IC TL431CZ
IC8301 8-752-096-06 IC CXA2163Q-T6
IC8302 8-759-485-79 IC TC7SET08FU(TE85R)
IC8601 8-759-182-88 IC PQ09TZ5U
IC8602 8-759-576-72 IC LF50CDT-TR
IC8603 8-759-576-72 IC LF50CDT-TR
IC8604 8-759-576-72 IC LF50CDT-TR
IC8801 8-752-096-83 IC CXA2149AQ-TL
< SOCKET >
J8901 1-774-747-11 JACK BLOCK, PIN
J
