118
REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
R8310 1-216-037-00 RES-CHIP 330 5% 1/10W
R8312 1-216-091-00 RES-CHIP 56K 5% 1/10W
R8313 1-216-081-00 RES-CHIP 22K 5% 1/10W
R8314 1-216-295-91 SHORT 0
R8315 1-216-121-91 RES-CHIP 1M 5% 1/10W
R8316 1-216-037-00 RES-CHIP 330 5% 1/10W
R8317 1-216-295-91 SHORT 0
R8318 1-216-295-91 SHORT 0
R8319 1-216-295-91 SHORT 0
R8320 1-216-041-00 RES-CHIP 470 5% 1/10W
R8322 1-216-049-91 RES-CHIP 1K 5% 1/10W
R8323 1-216-017-91 RES-CHIP 47 5% 1/10W
R8324 1-216-041-00 RES-CHIP 470 5% 1/10W
R8326 1-216-017-91 RES-CHIP 47 5% 1/10W
R8328 1-216-025-91 RES-CHIP 100 5% 1/10W
R8329 1-216-025-91 RES-CHIP 100 5% 1/10W
R8330 1-216-041-00 RES-CHIP 470 5% 1/10W
R8331 1-216-041-00 RES-CHIP 470 5% 1/10W
R8332 1-216-041-00 RES-CHIP 470 5% 1/10W
R8333 1-216-041-00 RES-CHIP 470 5% 1/10W
R8334 1-216-041-00 RES-CHIP 470 5% 1/10W
R8336 1-216-041-00 RES-CHIP 470 5% 1/10W
R8337 1-216-041-00 RES-CHIP 470 5% 1/10W
R8338 1-216-017-91 RES-CHIP 47 5% 1/10W
R8339 1-216-017-91 RES-CHIP 47 5% 1/10W
R8340 1-216-063-91 RES-CHIP 3.9K 5% 1/10W
R8341 1-216-041-00 RES-CHIP 470 5% 1/10W
R8344 1-216-091-00 RES-CHIP 56K 5% 1/10W
R8345 1-216-079-00 RES-CHIP 18K 5% 1/10W
R8346 1-216-091-00 RES-CHIP 56K 5% 1/10W
R8347 1-216-079-00 RES-CHIP 18K 5% 1/10W
R8551 1-216-295-91 SHORT 0
R8552 1-216-295-91 SHORT 0
R8553 1-216-295-91 SHORT 0
R8806 1-216-085-00 RES-CHIP 33K 5% 1/10W
R8807 1-216-089-91 RES-CHIP 47K 5% 1/10W
R8820 1-216-295-91 SHORT 0
R8826 1-216-051-00 RES-CHIP 1.2K 5% 1/10W
R8836 1-216-025-91 RES-CHIP 100 5% 1/10W
R8841 1-216-025-91 RES-CHIP 100 5% 1/10W
R8846 1-216-295-91 SHORT 0
R8854 1-216-029-00 RES-CHIP 150 5% 1/10W
R8855 1-216-031-00 RES-CHIP 180 5% 1/10W
R8856 1-216-055-91 RES-CHIP 1.8K 5% 1/10W
R8857 1-216-089-91 RES-CHIP 47K 5% 1/10W
R8858 1-216-079-00 RES-CHIP 18K 5% 1/10W
R8859 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R8861 1-216-295-91 SHORT 0
R8863 1-216-295-91 SHORT 0
R8865 1-216-022-00 RES-CHIP 75 5% 1/10W
R8866 1-216-022-00 RES-CHIP 75 5% 1/10W
R8867 1-216-049-91 RES-CHIP 1K 5% 1/10W
R8868 1-216-017-91 RES-CHIP 47 5% 1/10W
R8869 1-216-017-91 RES-CHIP 47 5% 1/10W
R8871 1-216-049-91 RES-CHIP 1K 5% 1/10W
R8872 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R8873 1-216-113-00 RES-CHIP 470K 5% 1/10W
R8874 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R8875 1-216-113-00 RES-CHIP 470K 5% 1/10W
R8876 1-216-093-91 RES-CHIP 68K 5% 1/10W
R8877 1-216-093-91 RES-CHIP 68K 5% 1/10W
R8878 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R8879 1-216-689-11 METAL CHIP 39K 0.5% 1/10W
R8880 1-216-295-91 SHORT 0
R8881 1-216-089-91 RES-CHIP 47K 5% 1/10W
R8882 1-216-079-00 RES-CHIP 18K 5% 1/10W
R8883 1-216-645-11 METAL CHIP 560 0.5% 1/10W
R8885 1-216-645-11 METAL CHIP 560 0.5% 1/10W
R8888 1-216-033-00 RES-CHIP 220 5% 1/10W
R8889 1-216-033-00 RES-CHIP 220 5% 1/10W
R8890 1-216-295-91 SHORT 0
R8892 1-216-295-91 SHORT 0
R8893 1-216-295-91 SHORT 0
R8900 1-216-039-00 RES-CHIP 390 5% 1/10W
R8901 1-216-049-91 RES-CHIP 1K 5% 1/10W
R8902 1-216-039-00 RES-CHIP 390 5% 1/10W
R8903 1-216-089-91 RES-CHIP 47K 5% 1/10W
R8904 1-216-089-91 RES-CHIP 47K 5% 1/10W
R8905 1-216-113-00 RES-CHIP 470K 5% 1/10W
R8906 1-216-035-00 RES-CHIP 270 5% 1/10W
R8907 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R8908 1-216-035-00 RES-CHIP 270 5% 1/10W
R8909 1-216-049-91 RES-CHIP 1K 5% 1/10W
R8911 1-216-025-91 RES-CHIP 100 5% 1/10W
R8913 1-216-022-00 RES-CHIP 75 5% 1/10W
R8914 1-216-071-00 RES-CHIP 8.2K 5% 1/10W
R8915 1-216-022-00 RES-CHIP 75 5% 1/10W
R8916 1-216-017-91 RES-CHIP 47 5% 1/10W
R8917 1-216-017-91 RES-CHIP 47 5% 1/10W
R8918 1-216-113-00 RES-CHIP 470K 5% 1/10W
R8919 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R8922 1-216-022-00 RES-CHIP 75 5% 1/10W
R8923 1-216-022-00 RES-CHIP 75 5% 1/10W
R8924 1-216-022-00 RES-CHIP 75 5% 1/10W
