REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK
The components identified by
shading and marked are critical
for safety
Replace only with the part number
specified.
< FERRITE BEAD >
FB5400 1-535-143-61 LEAD, JUMPER (5.0MM)
FB5401 1-535-143-61 LEAD, JUMPER (5.0MM)
< COIL >
L5400 1-410-784-41 INDUCTOR 0.18UH
L5401 1-408-602-31 INDUCTOR 8.2UH
< TRANSISTOR >
Q5400 8-729-119-78 TRANSISTOR 2SC1740S-RT
Q5401 8-729-119-78 TRANSISTOR 2SC1740S-RT
Q5402 8-729-119-78 TRANSISTOR 2SC1740S-RT
Q5403 8-729-119-78 TRANSISTOR 2SC1740S-RT
Q5404 8-729-026-39 TRANSISTOR 2SA933AS-RT
Q5405 8-729-026-39 TRANSISTOR 2SA933AS-RT
Q5406 8-729-045-05 TRANSISTOR 2SA2005
Q5407 8-729-045-04 TRANSISTOR 2SC5511
Q5408 8-729-026-39 TRANSISTOR 2SA933AS-RT
Q5409 8-729-119-78 TRANSISTOR 2SC1740S-RT
< RESISTOR >
R5401 1-247-843-11 CARBON 3.3K 5% 1/4W
R5402 1-249-413-11 CARBON 470 5% 1/4W
R5403 1-249-393-11 CARBON 10 5% 1/4W
R5404 1-249-420-11 CARBON 1.8K 5% 1/4W
R5405 1-249-425-11 CARBON 4.7K 5% 1/4W
R5406 1-249-425-11 CARBON 4.7K 5% 1/4W
R5407 1-249-399-11 CARBON 33 5% 1/4W
R5408 1-247-807-31 CARBON 100 5% 1/4W
R5409 1-249-409-11 CARBON 220 5% 1/4W
R5410 1-249-401-11 CARBON 47 5% 1/4W
R5411 1-249-401-11 CARBON 47 5% 1/4W
R5412 1-249-429-11 CARBON 10K 5% 1/4W
R5413 1-249-414-11 CARBON 560 5% 1/4W
R5414 1-249-432-11 CARBON 18K 5% 1/4W
R5415 1-247-739-11 CARBON 100 5% 1/2W
R5416 1-249-389-11 CARBON 4.7 5% 1/4W
R5417 1-249-432-11 CARBON 18K 5% 1/4W
R5418 1-249-414-11 CARBON 560 5% 1/4W
R5419 1-249-421-11 CARBON 2.2K 5% 1/4W
R5420 1-249-421-11 CARBON 2.2K 5% 1/4W
R5421 1-249-387-11 CARBON 3.3 5% 1/4W
R5422 1-249-405-11 CARBON 100 5% 1/4W
R5423 1-215-915-11 METAL OXIDE 470 5% 3W
R5425 1-535-143-61 LEAD, JUMPER (5.0MM)
R5427 1-249-401-11 CARBON 47 5% 1/4W
R5428 1-249-413-11 CARBON 470 5% 1/4W
R5429 1-249-413-11 CARBON 470 5% 1/4W
R5430 1-249-417-11 CARBON 1K 5% 1/4W
R5432 1-249-415-11 CARBON 680 5% 1/4W
R5433 1-249-400-11 CARBON 39 5% 1/4W
R5434 1-249-395-11 CARBON 15 5% 1/4W
VM
