Sony FD Trinitron KV-32CS70B - Page 74

REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK
- 74 -
F5
R7304 1-260-095-11 CARBON 470 5% 1/2W
R7305 1-215-903-11 METAL OXIDE 68K 5% 2W
R7306 1-535-303-00 LEAD, JUMPER (5.0MM)
R7309 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R7310 1-216-819-11 METAL CHIP 680 5% 1/10W
R7325 1-249-417-11 CARBON 1K 5% 1/4W
R7327 1-535-303-00 LEAD, JUMPER (5.0MM)
R7328 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R7329 1-260-095-11 CARBON 470 5% 1/2W
R7330 1-215-903-11 METAL OXIDE 68K 5% 2W
R7331 1-535-303-00 LEAD, JUMPER (5.0MM)
R7334 1-216-819-11 METAL CHIP 680 5% 1/10W
R7335 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R7350 1-249-417-11 CARBON 1K 5% 1/4W
R7355 1-535-303-00 LEAD, JUMPER (5.0MM)
R7356 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R7357 1-260-095-11 CARBON 470 5% 1/2W
R7358 1-215-903-11 METAL OXIDE 68K 5% 2W
R7360 1-535-303-00 LEAD, JUMPER (5.0MM)
R7363 1-216-819-11 METAL CHIP 680 5% 1/10W
R7364 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R7373 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R7374 1-216-819-11 METAL CHIP 680 5% 1/10W
R7375 1-249-435-11 CARBON 33K 5% 1/4W
R7376 1-249-429-11 CARBON 10K 5% 1/4W
R7377 1-249-430-11 CARBON 12K 5% 1/4W
R7379 1-216-833-11 METAL CHIP 10K 5% 1/10W
R7380 1-216-833-11 METAL CHIP 10K 5% 1/10W
R7381 1-216-833-11 METAL CHIP 10K 5% 1/10W
R7382 1-202-549-00 SOLID 100 20% 1/2W
R7383 1-216-349-00 METAL OXIDE 1 5% 1W
R7385 1-202-549-00 SOLID 100 20% 1/2W
R7387 1-247-735-11 CARBON 47 5% 1/2W
R7388 1-535-143-51 LEAD, JUMPER (20.0MM)
R7389 1-247-881-00 CARBON 120K 5% 1/4W
R7390 1-249-417-11 CARBON 1K 5% 1/4W
R7391 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R7392 1-216-819-11 METAL CHIP 680 5% 1/10W
R7393 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R7394 1-249-417-11 CARBON 1K 5% 1/4W
R7395 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R7396 1-216-819-11 METAL CHIP 680 5% 1/10W
R7397 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R7398 1-249-417-11 CARBON 1K 5% 1/4W
R7399 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
< RESISTOR VARIABLE >
RV7375 1-241-656-11 RES, ADJ, METAL FILM 110M
* A-1410-981-A F5 Board Complete
4-206-220-01 HOLDER, LED
* 4-374-846-01 COVER, CAPACITOR, CAP TYPE
< CAPACITOR >
C1100 1-126-969-11 ELECT 220UF 20.00% 50V
C1101 1-113-924-11 CERAMIC 0.0047UF 20.00% 250V
< CONNECTOR >
CN1101 * 1-580-797-11 SOCKET, CONNECTOR 4P
CN6100 £ * 1-580-843-11 PIN, CONNECTOR (POWER)
CN6101 1-695-915-11 TAB (CONTACT)
CN6102 £ * 1-691-291-11 PIN, CONNECTOR (PC BOARD) 5P
< DIODE >
D1100 8-719-109-89 DIODE RD5.6ESB2
D6401 8-719-081-56 DIODE L-59SRSGC-CC
< FUSE >
F001 £ 1-576-232-12 FUSE 5A 250V
FH001 £ 1-533-725-11 FUSE HOLDER
< IC >
IC6400 8-742-180-30 HYB IC SBX3081-51(30)
< TRANSISTOR >
Q1100 8-729-027-38 TRANSISTOR DTA144EKA-T146
Q1101 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R1100 1-216-813-11 METAL CHIP 220 5% 1/10W
R1101 1-216-815-11 METAL CHIP 330 5% 1/10W
R1102 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1103 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1104 1-216-813-11 METAL CHIP 220 5% 1/10W
R1105 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1106 1-216-809-11 METAL CHIP 100 5% 1/10W
R6100 £ 1-202-719-00 SOLID 1M 10% 1/2W
< SWITCH >
S6100 £ 1-571-433-21 SWITCH, AC POWER PUSH
< VARISTOR >
VD6100 £ 1-803-830-11 VARISTOR (ERZV14D621)
C
