HCD-H7/H1500
Ref.No. Part No. Description Ref.No. Part No. Description
R709
1-249-421-11
CARBON
2.2K
5%
1/4W
R794A
1-249-414-11
CARBON
560
5%
1/4W
R710 1-249-421-11 CARBON 2.2K 5% 1/4W R794B 1-249-433-11 (AEP ,UK,WG,1T)
R712 1-249-425-11 CARBON 4.7K 5% 1/4W . . CARBON 22k 5% 1/4W
R713 1-249-426-11 CARBON 5.6K 5% 1/4W
R795 1-249-435-11 (AEP,UK,WG,IT)
R731 1-249-417-11 (AEP,UK,WG,IT) .. CARBON 33K 5% = «1 /4W
. . CARBON 1K 5% 1/4W R801 1-249-417-11 CARBON 1K 5% = 1/4W
R731 1-249-425-11 (US,Canadian,E ,EA,AUS)
. » CARBON 4.7K 5% 1/4W R802 1-249-438-11 CARBON 560K 5% 1/4W
R803 1-249-413-11 CARBON 470 5% 1/4W
R732 1-249-437-11 CARBON 47K 5% 1/4W R804 1-249-438-11 CARBON 56K «65%: /4W
R733: 1-249-437-11 (AEP,UK,WG,1T)
. » CARBON 47K 5% 1/4W R805 1-249-389-11 CARBON 4.7 5% 1/4W
R851 1-249-417-11 CARBON 1K 5% = 1/4W
R734: 1-247-897-11 (AEP ,UK,WG, IT) R852 1-249-438-11 CARBON 56K 5% 1/4W
. » CARBON 560K 5% 1/4W
R735: 1-249-417-11 (AEP ,UK,WG,IT) R853: 1-249-413-11 CARBON 470 5% 1/4W
. » CARBON 1K 65% = 1/4W R854 = 1-249-438-11 CARBON 56K «=65%—Ss«O AW
R855. 1-249-389-11 CARBON 4.7 5% 1/4W
R737 1-249-437-11 (AEP,UK,WG,IT)
. » CARBON 47K 5% 1/4W R856 = 1-249-417-11 CARBON 1K 5% 1/4W
R738 1-249-425-11 CARBON 4.7K 5% 1/4W R871 1-249-429-11 CARBON 10K 35% 1/4W
R872 1-249-437-11 CARBON ATK 5% 1/4W
R740 1-249-425-11 CARBON 4.7K 5% 1/4W
R742 1-249-405-11 CARBON 100 5% 1/4W R873. -:1-249-429-11 CARBON 10K 5% 1/4W
R744 1-249-429-11 CARBON 10K 5% 1/4W R874 1-247-883-00 CARBON 150K 5% 1/4W
R875: 1-249-421-11 CARBON 2.2K 5% 1/4
R745. 1-249-429-11 CARBON 10K 5% 1/4W
R746 = 1-249-429-11 CARBON 10K 5% 1/4W R876 1-249-421-11 CARBON 2.2K 5% 1/4W
R747 1-249-405-11 CARBON 100 5% 1/4W R877 A.1-212-881-11 FUSIBLE 100 5% 1/4W F
R878 1-249-417-11 CARBON 1K 5% ~=1/4W
R748 1-249-405-11 CARBON 100 5% 1/4W
R752 1-249-431-11 CARBON 15K 5% 1/4W R879 +1-249-417-11 CARBON 1K 5%, 1/4W
R753 -1-249-437-11 CARBON 47K 5% = 1 /4W R880 A\.1-212-881-11 FUSIBLE 100 5% 1/4W F
R881 1-249-421-11 CARBON 2.2K 5% 1/4
R754 1-249-422-11 (US,Canadian)
. + «CARBON 2.7K 5% 1/4W R882 1-249-421-11 CARBON 2.2K 5% 1/4W
R754 1-249-426-11 (EXCEPT FOR US,Canadian) R883 A.1-212-881-11 FUSIBLE 100 «5% 1/4W oF
» » CARBON 5.6K 5% 1/4W R901 1-249-419-11 CARBON 1.5K 5% 1/4W
R755: 1-249-429-11 CARBON 10K 5% = 1 /4W R902. 1-249-429-11 CARBON 10K 5% 1/4W
R757 1-249-437-11 CARBON 47K 5% = 1 /4W R903: 1-249-421-11 CARBON 2.2K 5% 1/4W
R758 1-249-437-11 CARBON 47K = 5% 1/4W R904 ~=«- 1-249-433-11 CARBON 22K «45% 1/4W
R759: 1-249-421-11 CARBON 2.2K 5% 1/4W R905 A\.1-212-934-00 (Except for US, Canadian)
R760 1-249-421-11 CARBON 2.2K 5% 1/4W 2. FUSIBEE 1 5% L/2W F
R762 = 1-249-425-11 CARBON 4.7K 5% 1/4W R905 A 1-212-942-00 (US,Canadian)
; ..»FUSIBLE 2.2 5% 1/2W F
R763 1-249-426-11 CARBON 5.6K 5% = 1/4W R906 A\.1-212-934-00 FUSIBLE 1 5% «1/2W«*F
R771 1-249-429-11 CARBON 10K 5% 1/4 R907 A\.1-212-934-00 (Except for US, Canadian)
R773. 1-247-870-11 CARBON 43k 5% 1 /4W RUM AleeeHo Se ae, “a 1/2 F
R774 1-249-437-11 CARBON 47K 5% =1/4W ’
Rilo beeen ae eee Hi ee a R908 1-249-425-11 CARBON 4.7K 5% 1/4W
R776 1-249-437-11 CARBON 47K 5&1 /4W R909 1-249-433-11 CARBON 22k 5% («1 /AW
R910 1-247-903-00 CARBON IM 5% ~~ /4W
R781 1-249-417-11 (AEP,UK,WG,IT)
. » CARBON 1K = 5%. /4W R911 1-249-405-11 CARBON 100 5% 1/4W
R781 1-249-425-11 (US,Canadian,£,£A,AUS) R912. 1-249-432-11 CARBON 18K 5% 1/4
. - «CARBON 4.7K 5% 1/4W R913. 1-249-432-11 CARBON 18K 5% 1/4W
R782. 1-249-437-11 CARBON 47K 5% 1/4W R914: 1-247-842-11 CARBON 3K 5% OL /4W
R783 1-249-437-11 (AEP,UK,WG, IT) R915 1-249-429-11 CARBON 10K 5% 1/4W
. . CARBON 47K 5% 1/4W R917: 1-249-413-11 CARBON 470 5% 1/4W
R926 =: 1-202-725-00 (US,Canadian)
R784 =: 1-247-897-11 (AEP,UK,WG, IT) ...SOLID 3.3M 10% 1/2W
.. CARBON 560K 5% 1/4W RB502 1-233-206-11 COMPOSITION CIRCUIT BLOCK (100KX13)
R785 1-249-417-11 (AEP,UK,WG,IT)
. . CARBON 1K 5%) 1/4 RV41A 1-228-989-00 RES, ADJ, CARBON 470
R787 1-249-437-11 (AEP,UK,WG,IT) RV41B 1-228-989-00 RES, ADJ, CARBON 470
.. CARBON 47K 5% 1/4W RV42B 1-230-500-11 RES, ADJ, CARBON 220K
R788 1-249-425-11 CARBON 4.7K 5% 1/4W RV61A 1-228-989-00 RES, ADJ, CARBON 470
R790 1-249-425-11 CARBON 4.7K 5% 1/4W RV61B 1-228-989-00 RES, ADJ, CARBON 470
R791 1-249-417-11 CARBON 1K «65% ~—s1/4W RV62B 1-230-500-11 RES, ADJ, CARBON 220K
R792 1-249-411-11 CARBON 330 5% 1/4W
Note: Note:
The components identi- | Les composanss identifiés par
fied by mark or dot- | une marque A\ sont critiques
ted line with mark A pour la sécurité.
are critical for safety. Ne les remplacer que par une
Replace only with part | piéce portant le numéro spéci-
—66— number specified. fié.
