4-50E
GV-HD700/HD700E_L2
: Uses unleaded solder.
FP-031 (1 layer), FP-032 (1 layer), FP-228 (1 layer)
FP-031, FP-032, FP-228
M902
LOADING MOTOR
S903
MODE SWITCH
M
(Dilect Solder)
(Dilect Solder)
1
14
2
1-677-049-
11
1-867-810-
11
1-867-811-
12
12
29
08
1
FP-228 FLEXIBLE BOARD
FP-032 FLEXIBLE BOARD
FP-031 FLEXIBLE BOARD
S902
(REC PROOF)
S901
(CC DOWN)
D902
(TAPE LED)
H902
T REEL SENSOR
H901
S REEL SENSOR
MIC901
Q902
TAPE TOP SENSOR
4 PIN
CONNECTOR
Q901
TAPE END SENSOR
GND
VCC
-
+
GND
VCC
-
+
05
Note: The FP-031 and FP-032 are supplied as the assembled part of
the MD (N210) sub ass'y (S) A by attaching them with the adhesive agent.
These parts are not separately supplied because assembling of
these parts requires high accuracy.
DEW
SENSOR
Ver. 1.1 2007.09
The changed portions from
Ver. 1.0 are shown in blue.
To Next Page
