Sony HCD-DX155 - MAIN; < TRANSISTOR >; < SHORT >; < COIL >

82
HCD-DX155/DX255
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
IC511 6-708-922-01 IC PST3635NR
IC516 6-703-547-01 IC TA7805LS
IC1101 6-707-535-01 IC CXD9849R
IC1102 6-806-742-01 IC MX29LV320CBTC70-CBA1-0603CE
(DX155: E3, AUS)
IC1102 6-806-743-01 IC MX29LV320CBTC70-CBA1-0603GA
(DX155: SP)
IC1102 6-806-741-01 IC MX29LV320CBTC70-CBA1-0603UC
(DX155: US, CND, MX/DX255)
✩ IC1103 not supplied IC BR24L64F-WE2
IC1104 6-709-370-01 IC A2V64S40CTP-G75
IC1105 6-702-302-01 IC TK11133CSCL-G
IC1107 6-702-302-01 IC TK11133CSCL-G
IC1109 6-707-485-01 IC NJM2885DL1-18 (TE2)
IC1201 6-704-524-01 IC FAN8036L
IC2200 6-707-608-01 IC PCM1803DBR
IC3001 8-759-710-97 IC NJM4565M (TE2)
IC3003 8-759-680-48 IC TC7WH157FK (TE85R)
IC3010 6-705-979-01 IC CXD9788AR
IC3020 6-705-979-01 IC CXD9788AR
IC3030 6-705-979-01 IC CXD9788AR
IC3050 6-702-300-01 IC TK11118CSCL-G
IC3051 8-759-649-50 IC SN74AHC1GU04DCKR
IC3100 6-708-921-01 IC CXD9883M
IC3150 6-708-921-01 IC CXD9883M
IC3200 6-708-921-01 IC CXD9883M
IC3250 6-708-921-01 IC CXD9883M
IC3300 6-708-921-01 IC CXD9883M
IC3400 6-708-921-01 IC CXD9883M
IC3500 6-708-921-01 IC CXD9883M (DX255)
< SHORT >
JC508 1-216-864-11 SHORT CHIP 0 (DX155)
JC509 1-216-864-11 SHORT CHIP 0 (DX255)
JC511 1-216-864-11 SHORT CHIP 0 (DX155: SP)
JC512 1-216-864-11 SHORT CHIP 0 (DX155: E3)
JC513 1-216-864-11 SHORT CHIP 0 (DX155: AUS)
JC515 1-216-864-11 SHORT CHIP 0 (DX155: US, CND/DX255)
JC517 1-216-864-11 SHORT CHIP 0 (DX155: MX)
< COIL >
L2200 1-414-754-11 INDUCTOR 10uH
L2201 1-216-295-91 SHORT CHIP 0
L3000 1-469-527-91 INDUCTOR 47uH
L3051 1-414-754-11 INDUCTOR 10uH
L3052 1-414-754-11 INDUCTOR 10uH
L3053 1-414-754-11 INDUCTOR 10uH
L3054 1-412-939-11 INDUCTOR 1uH
L3111 1-456-680-11 INDUCTOR 10uH
L3112 1-456-680-11 INDUCTOR 10uH
L3151 1-456-680-11 INDUCTOR 10uH
L3152 1-456-680-11 INDUCTOR 10uH
L3201 1-456-680-11 INDUCTOR 10uH
L3202 1-456-680-11 INDUCTOR 10uH
L3251 1-456-680-11 INDUCTOR 10uH
L3252 1-456-680-11 INDUCTOR 10uH
L3301 1-456-680-11 INDUCTOR 10uH
L3302 1-456-680-11 INDUCTOR 10uH
L3401 1-456-680-11 INDUCTOR 10uH
L3402 1-456-680-11 INDUCTOR 10uH
L3501 1-456-680-11 INDUCTOR 10uH (DX255)
L3502 1-456-680-11 INDUCTOR 10uH (DX255)
< TRANSISTOR >
Q502 6-550-718-01 TRANSISTOR RSR025N03TL
Q506 8-729-120-28 TRANSISTOR 2SC3052EF-T1-LEF
Q1101 6-550-008-01 TRANSISTOR UM6K1N-TN
Q1102 6-550-653-01 TRANSISTOR QST8TR
Q1103 8-729-027-52 TRANSISTOR RT1N241C-TP-1
Q3000 8-729-142-48 TRANSISTOR 2SD1616-TP-LK
Q3001 8-729-120-28 TRANSISTOR 2SC3052EF-T1-LEF
Q3002 8-729-120-28 TRANSISTOR 2SC3052EF-T1-LEF
Q3081 8-729-027-23 TRANSISTOR RT1P141C-TP-1
Q3101 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q3102 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q3151 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q3152 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q3201 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q3202 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q3251 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q3252 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q3301 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q3302 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q3401 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q3402 8-729-600-22 TRANSISTOR 2SA1235TP-1EF
Q3551 8-729-120-28 TRANSISTOR 2SC3052EF-T1-LEF
< RESISTOR >
R506 1-216-821-11 METAL CHIP 1K 5% 1/10W
R507 1-216-841-11 METAL CHIP 47K 5% 1/10W
R513 1-216-821-11 METAL CHIP 1K 5% 1/10W
R515 1-216-821-11 METAL CHIP 1K 5% 1/10W
R519 1-216-809-11 METAL CHIP 100 5% 1/10W
R524 1-216-833-11 METAL CHIP 10K 5% 1/10W
R577 1-216-821-11 METAL CHIP 1K 5% 1/10W
(DX155)
R577 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
(DX255)
R585 1-216-809-11 METAL CHIP 100 5% 1/10W
R586 1-216-809-11 METAL CHIP 100 5% 1/10W
R587 1-216-809-11 METAL CHIP 100 5% 1/10W
R588 1-216-809-11 METAL CHIP 100 5% 1/10W
R589 1-216-809-11 METAL CHIP 100 5% 1/10W
R590 1-216-809-11 METAL CHIP 100 5% 1/10W
R591 1-216-809-11 METAL CHIP 100 5% 1/10W
R592 1-216-833-11 METAL CHIP 10K 5% 1/10W
R593 1-216-833-11 METAL CHIP 10K 5% 1/10W
R594 1-216-809-11 METAL CHIP 100 5% 1/10W
R595 1-216-809-11 METAL CHIP 100 5% 1/10W
R596 1-216-821-11 METAL CHIP 1K 5% 1/10W
(DX155: SP)
R596 1-216-833-11 METAL CHIP 10K 5% 1/10W
(DX155: E3)
R596 1-216-835-11 METAL CHIP 15K 5% 1/10W
(DX155: AUS)
MAIN
✩ New part of EEP ROM (IC1103) on the MAIN board cannot be used.
Therefore, if the mounted MAIN board (A-1151-985-A, etc.) is replaced,
exchange new EEP ROM (IC1103) with that used before the replacement.
Ver. 1.2
