Sony HCD-EC68P - Page 58

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EC68P/EC78P
58
C847 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C848 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C850 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< FILTER >
CF801 1-781-962-21 FILTER, CERAMIC
< CONNECTOR >
CN601 1-819-131-11 PIN, CONNECTOR 3P
CN602 1-784-766-11 CONNECTOR, FFC 5P (EC78P)
CN603 1-784-766-11 CONNECTOR, FFC 5P
CN604 1-819-136-11 PIN, CONNECTOR 8P
CN605 1-784-770-11 CONNECTOR, FFC 9P
CN608 1-779-289-11 CONNECTOR, FFC (LIF (NON-ZIF)) 21P
CN609 1-779-279-11 CONNECTOR, FFC (LIF (NON-ZIF)) 11P
CN632 1-824-030-21 HOLDER, CABLE 5P (EC78P)
CN633 1-819-133-11 PIN, CONNECTOR
* CN801 1-506-680-11 PLUG, CONNECTOR (2.5mm) 3P
(ANTENNA FM/AM)
CN803 1-784-792-11 CONNECTOR, FFC 31P
< DIODE >
D601 6-500-335-01 DIODE MC2838-T112-1
D602 6-500-335-01 DIODE MC2838-T112-1
D603 6-501-817-01 DIODE MA2J1110GLS0 (EC78P)
D604 6-501-817-01 DIODE MA2J1110GLS0
D605 6-501-817-01 DIODE MA2J1110GLS0
D606 6-500-334-01 DIODE MC2836-T112-1
D607 6-501-046-01 DIODE 1N5402-F46
D608 6-501-046-01 DIODE 1N5402-F46
D609 6-501-046-01 DIODE 1N5402-F46
D610 6-501-046-01 DIODE 1N5402-F46
D611 8-719-046-07 DIODE 2A02M (EC78P)
D612 8-719-046-07 DIODE 2A02M (EC78P)
D614 6-501-817-01 DIODE MA2J1110GLS0
D615 8-719-063-79 DIODE 1N4002B
D617 6-500-335-01 DIODE MC2838-T112-1
D618 6-501-719-01 DIODE MAZ8039GHLS0
D619 8-719-063-79 DIODE 1N4002B
D620 8-719-063-79 DIODE 1N4002B
D621 6-501-722-01 DIODE MAZ8043GMLS0
D622 6-501-752-01 DIODE MAZ8082GMLS0
D628 6-501-817-01 DIODE MA2J1110GLS0
D629 8-719-063-79 DIODE 1N4002B (EC68P)
D630 8-719-063-79 DIODE 1N4002B (EC68P)
D631 6-501-817-01 DIODE MA2J1110GLS0
D701 8-719-079-47 DIODE RK36LF-A4
D791 6-501-817-01 DIODE MA2J1110GLS0
D801 6-501-142-01 DIODE SVC347A-TL-E
D802 8-719-062-51 DIODE 1PS226-115
D803 6-501-369-01 DIODE SVC230-TB-E
D804 6-501-369-01 DIODE SVC230-TB-E
D805 8-719-062-51 DIODE 1PS226-115
D806 8-719-062-51 DIODE 1PS226-115
< GROUND TERMINAL >
ET601 1-537-771-21 TERMINAL BOARD, GROUND
ET602 1-537-771-21 TERMINAL BOARD, GROUND
< FILTER >
FL801 1-760-393-11 FILTER, CERAMIC
FL803 1-236-711-21 FILTER, BAND PASS
< IC >
IC602 6-712-055-01 IC BD3499FV-E2
IC701 6-712-088-01 IC BD9701CP-V5
IC770 8-759-278-58 IC NJM4558V-TE2
IC801 6-708-840-01 IC LV23003VA
< JUMPER RESISTOR >
JR601 1-216-864-11 SHORT CHIP 0
JR602 1-216-864-11 SHORT CHIP 0
JR603 1-216-864-11 SHORT CHIP 0
JR604 1-216-864-11 SHORT CHIP 0
JR605 1-216-864-11 SHORT CHIP 0
JR606 1-216-864-11 SHORT CHIP 0
JR607 1-216-864-11 SHORT CHIP 0
JR608 1-216-864-11 SHORT CHIP 0
JR609 1-216-864-11 SHORT CHIP 0
JR610 1-216-864-11 SHORT CHIP 0
JR611 1-216-864-11 SHORT CHIP 0
JR612 1-216-864-11 SHORT CHIP 0
JR613 1-216-864-11 SHORT CHIP 0
JR614 1-216-864-11 SHORT CHIP 0
JR615 1-216-864-11 SHORT CHIP 0
JR616 1-216-864-11 SHORT CHIP 0
JR617 1-216-864-11 SHORT CHIP 0
JR618 1-216-864-11 SHORT CHIP 0
< COIL >
L601 1-456-107-11 COIL, AIR-CORE (EC78P)
L602 1-456-107-11 COIL, AIR-CORE (EC78P)
L603 1-456-107-11 COIL, AIR-CORE
L604 1-456-107-11 COIL, AIR-CORE
L701 1-456-467-11 INDUCTOR 100uH
L801 1-456-596-11 COIL, MW OSC
L802 1-457-168-11 COIL, DET
L803 1-457-162-11 COIL, AIR-CORE
L804 1-457-163-11 COIL, AIR-CORE
L805 1-457-161-11 COIL, AM ANTENNA
< TRANSISTOR >
Q601 8-729-037-03 TRANSISTOR KTA1266GR-AT
Q602 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q603 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q604 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q605 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q606 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q608 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q611 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q612 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q618 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q619 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q622 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q624 8-729-036-86 TRANSISTOR KTC3203Y-AT
Q761 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q762 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q801 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q802 8-729-120-28 TRANSISTOR 2SC1623-L5L6
MAIN
