Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-EC68P/EC78P
6161
< CAPACITOR >
C301 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C302 1-126-964-11 ELECT 10uF 20% 50V
C303 1-126-964-11 ELECT 10uF 20% 50V
C304 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C305 1-126-964-11 ELECT 10uF 20% 50V
C306 1-104-655-91 ELECT 470uF 20% 6.3V
C308 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
(EC78P: UK)
C309 1-126-965-91 ELECT 22uF 20% 50V
(EC78P: UK)
C310 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(EC78P: UK)
C311 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(EC78P: UK)
C312 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(EC78P: UK)
C313 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C314 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C315 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C316 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C317 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C319 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C320 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C321 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C328 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C330 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C332 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C338 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C340 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C341 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C342 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C343 1-126-965-91 ELECT 22uF 20% 50V
(EC78P: UK)
C344 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
(EC78P: UK)
C345 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
(EC78P: UK)
C346 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C347 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C348 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C351 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(EC68P/EC78P: US, CND)
C352 1-126-964-11 ELECT 10uF 20% 50V
(EC68P/EC78P: US, CND)
C353 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(EC68P/EC78P: US, CND)
C354 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C355 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C356 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C357 1-126-965-91 ELECT 22uF 20% 50V
(EC68P/EC78P: US, CND)
< CONNECTOR >
CN301 1-784-753-11 CONNECTOR, FFC 31P
CN302 1-784-735-11 CONNECTOR, FFC 13P (EC78P: UK)
CN303 1-815-550-11 PIN, CONNECTOR (PWB) 2P
CN306 1-815-443-11 PIN, CONNECTOR (PWB) 2P
CN311 1-779-273-11 CONNECTOR, FFC (LIF (NON-ZIF)) 5P
(EC68P/EC78P: US, CND)
< DIODE >
D301 6-501-722-01 DIODE MAZ8043GMLS0
D302 6-501-817-01 DIODE MA2J1110GLS0
D303 6-500-334-01 DIODE MC2836-T112-1
D304 6-501-817-01 DIODE MA2J1110GLS0
D305 6-501-817-01 DIODE MA2J1110GLS0 (EC78P: UK)
D306 8-719-063-79 DIODE 1N4002B (EC68P/EC78P: US, CND)
D307 6-501-817-01 DIODE MA2J1110GLS0
(EC68P/EC78P: US, CND)
< FERRITE BEAD >
FB301 1-500-329-21 INDUCTOR, FERRITE BEAD
< IC >
IC301 A-1551-183-A IC MB90F831PF-G-SPE1 (for service)
(EC78P: UK)
IC301 A-1551-185-A IC MB90F831PF-G-SPE1 (for service)
(EC68P/EC78P: US, CND)
IC302 6-711-556-01 IC NJL24H400B-SA
IC303 8-759-598-69 IC BA6956AN (EC68P/EC78P: US, CND)
< JUMPER RESISTOR >
JR301 1-216-864-11 SHORT
CHIP 0
JR302 1-216-864-11 SHORT CHIP 0
JR303 1-216-864-11 SHORT CHIP 0
JR304 1-216-864-11 SHORT CHIP 0
JR305 1-216-864-11 SHORT CHIP 0
JR307 1-216-864-11 SHORT CHIP 0
JR308 1-216-864-11 SHORT CHIP 0
JR309 1-216-864-11 SHORT CHIP 0
JR310 1-216-864-11 SHORT CHIP 0
JR311 1-216-864-11 SHORT CHIP 0
JR313 1-216-864-11 SHORT CHIP 0
JR315 1-216-864-11 SHORT CHIP 0
< LIQUID CRYSTAL DISPLAY >
LCD301 1-802-584-11 DISPLAY PANEL, LIQUID
< LED >
LED301 6-501-479-01 LED 1L0341Y23E0CA602 (I/1, STANDBY)
< TRANSISTOR >
Q301 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q302 8-729-037-13 TRANSISTOR KTA1271Y
Q303 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q304 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q305 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q306 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q307 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
(EC78P: UK)
Q308 8-729-038-28 TRANSISTOR RT1N441C-TP-1 (EC78P: UK)
Q309 8-729-040-76 TRANSISTOR KTA1273-Y-AT (EC78P: UK)
Q310 8-729-120-28 TRANSISTOR 2SC1623-L5L6 (EC78P: UK)
Q311 8-729-024-43 TRANSISTOR 2SA1365-T112-1EF
(EC78P: UK)
Q312 8-729-024-43 TRANSISTOR 2SA1365-T112-1EF
(EC78P: UK)
Q313 8-729-024-43 TRANSISTOR 2SA1365-T112-1EF
(EC78P: UK)
