– 114 –
MISCELLANEOUS
*************
14 1-773-160-11 WIRE (FLAT TYPE) (21 CORE)
15 1-769-947-11 WIRE (FLAT TYPE) (11 CORE)
64 1-777-869-11 WIRE (FLAT TYPE) (10 CORE)
(EXCEPT US, CND)
64 1-777-871-11 WIRE (FLAT TYPE) (8 CORE) (US, CND)
65 1-777-936-11 WIRE (FLAT TYPE) (5 CORE) (EXCEPT US, CND)
66 1-773-051-11 WIRE (FLAT TYPE) (17 CORE)
74 1-769-909-11 WIRE (FLAT TYPE) (9 CORE)
104 1-777-870-11 WIRE (FLAT TYPE) (19 CORE)
106 1-233-514-11 ENCAPSULATED COMPONENT
(RX70: AEP, AED, CIS, EE, G, UK)
106 1-233-544-11 ENCAPSULATED COMPONENT
(D60/RX70: US, CND)
106 1-233-545-11 ENCAPSULATED COMPONENT
(GR7: E2, EA4, MX, TH, AUS)
106 1-233-546-11 ENCAPSULATED COMPONENT
(GR7: E3, EA3, HK, MY, SAF, SP, TW/GR7J)
108 1-751-086-11 WIRE (FLAT TYPE) (13 CORE)
(D60/GR7: E2, EA4, MX, TH, AUS/RX70: US, CND)
108 1-751-688-11 WIRE (FLAT TYPE) (13 CORE) (GR7: E2)
108 1-773-012-11 WIRE (FLAT TYPE) (15 CORE) (GR7: E3, EA3, HK
SAF, SP, TW/GR7J/RX70: AEP, AED, CIS, EE, G, UK)
! 113 1-751-326-31 CORD, POWER (TH)
! 114 1-690-609-21 CORD, POWER (US, CND)
! 115 1-575-653-11 CORD, POWER (E2, E3, MX)
! 116 1-569-007-11 ADAPTOR, CONVERSION 2P (E3)
! 117 1-569-008-11 ADAPTOR, CONVERSION 2P (EA3, MY, SP, TW)
! 118 1-575-651-11 CORD, POWER (EA3, EA4, HK, MY, SAF, SP, TW)
! 118 1-575-651-21 CORD, POWER (AEP, AED, CIS, EE, G)
! 119 1-690-608-11 CORD, POWER (AUS)
! 120 1-751-529-11 CORD, POWER (UK)
! 121 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (HK)
257 1-452-538-11 MAGNET
258 1-776-042-11 WIRE (FLAT TYPE) (8 CORE)
! 301 8-820-020-01 OPTICAL PICK-UP KSS-213D/Q-NP
302 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
HP101 1-500-093-11 HEAD, MAGNETIC (PLAYBACK) (DECK A)
HRPE1011-500-094-11 HEAD, MAGNETIC (REC/PB/ERASE) (DECK B)
M1 X-3371-223-1 MOTOR ASSY, CAPSTAN
M101 X-4917-523-4 MOTOR ASSY SPINDLE
M102 X-4917-504-1 MOTOR ASSY SLED
M2 A-2004-410-A MOTOR ASSY, DC (TRIGGER)
M701 A-4672-004-A MOTOR ASSY (TURN)
M801 A-4672-004-A MOTOR ASSY (SLED)
M901 1-698-792-11 FAN, DC (D60/GR7/GR7J/RX70: US, CND)
S811 1-473-335-11 ENCODER, ROTARY (BU,TRAY ADDRESS DET)
! T901 1-429-997-11 TRANSFORMER, POWER (D60/RX70: US)
! T901 1-429-998-11 TRANSFORMER, POWER
(RX70: AEP, AED, CIS, EE, G, UK)
! T901 1-429-999-11 TRANSFORMER, POWER (GR7/GR7J)
! T901 1-431-148-11 TRANSFORMER, POWER (RX70: CND)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-871-01 SCREW +BVTT 3X6 (S)
#2 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#3 7-685-650-79 SCREW +BVTP 3X16 TYPE2 IT-3
#4 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#5 7-621-775-10 SCREW +B 2.6X4
#6 7-621-255-15 SCREW +P 2X3
#7 7-685-533-19 SCREW +BTP 2.6X6 TYPE2 N-S
#8 7-685-131-19 SCREW +BTP 2.6X4 TYPE2 N-S
#9 7-685-862-09 SCREW +BVTT 2.6X6 (S)
#10 7-685-534-19 SCREW +BTP 2.6X8 TYPE2 N-S
#11 7-623-921-01 RING, RETAINING, CAPSTAN
#12 7-621-775-00 SCREW +B 2.6X3
#13 7-685-872-09 SCREW +BVTT 3X8 (S)
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
1-501-374-11 ANTENNA, LOOP (GR7: SAF)
1-501-659-11 ANTENNA (FM) (GR7: SAF)
8-917-581-90 REMOCON, SONY RM-SD70//M SET (GR7: SAF)
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
HCD-D60/GR7/GR7J/RX70
