Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 52 —
R257 1-216-033-00 METAL CHIP 220 5% 1/10W
R258 1-216-033-00 METAL CHIP 220 5% 1/10W
R259 1-216-033-00 METAL CHIP 220 5% 1/10W
R264 1-216-033-00 METAL CHIP 220 5% 1/10W
R265 1-216-033-00 METAL CHIP 220 5% 1/10W
R266 1-216-033-00 METAL CHIP 220 5% 1/10W
R267 1-216-033-00 METAL CHIP 220 5% 1/10W
R268 1-216-033-00 METAL CHIP 220 5% 1/10W
R269 1-216-033-00 METAL CHIP 220 5% 1/10W
R274 1-216-033-00 METAL CHIP 220 5% 1/10W
R275 1-216-033-00 METAL CHIP 220 5% 1/10W
R276 1-216-033-00 METAL CHIP 220 5% 1/10W
R277 1-216-033-00 METAL CHIP 220 5% 1/10W
R278 1-216-017-91 METAL GLAZE 47 5% 1/10W
R279 1-216-021-00 METAL CHIP 68 5% 1/10W
R280 1-216-025-91 METAL GLAZE 100 5% 1/10W
R281 1-216-029-00 METAL CHIP 150 5% 1/10W
R282 1-216-029-00 METAL CHIP 150 5% 1/10W
R283 1-216-033-00 METAL CHIP 220 5% 1/10W
R284 1-216-037-00 METAL CHIP 330 5% 1/10W
R285 1-216-041-00 METAL CHIP 470 5% 1/10W
R286 1-216-045-00 METAL CHIP 680 5% 1/10W
R287 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R288 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R289 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
< SWITCH >
S270 1-762-750-11 SWITCH, TACTILE (^)
S271 1-762-750-11 SWITCH, TACTILE (6OPEN/CLOSE)
S272 1-762-750-11 SWITCH, TACTILE (p)
S274 1-762-750-11 SWITCH, TACTILE (DISC-3)
S275 1-762-750-11 SWITCH, TACTILE (DISC-2)
S276 1-762-750-11 SWITCH, TACTILE (DISC-1)
S278 1-762-750-11 SWITCH, TACTILE (0)
S279 1-762-750-11 SWITCH, TACTILE ())
S280 1-762-750-11 SWITCH, TACTILE (DISK SKIP EX-CHANGE)
************************************************************
* 1-658-575-11 CONNECTOR BOARD
*****************
< CONNECTOR >
* CN701 1-568-946-11 PIN, CONNECTOR 8P
CN702 1-750-413-11 CONNECTOR, FFC/FPC 8P
< TRANSISTOR >
Q701 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R703 1-249-435-11 CARBON 33K 5% 1/4W
R704 1-249-429-11 CARBON 10K 5% 1/4W
R705 1-249-417-11 CARBON 1K 5% 1/4W F
************************************************************
* 1-650-669-11 LEAF SWITCH BOARD
*****************
< CONNECTOR >
CN1001 1-695-372-31 PIN, CONNECTOR (PC BOARD) 11P
< TRANSISTOR >
Q1001 8-749-010-90 TRANSISTOR PHOTO REFLECTOR
NJL5165KA-H
Q1002 8-749-010-90 TRANSISTOR PHOTO REFLECTOR
NJL5165KA-H
< RESISTOR >
R1001 1-247-818-11 CARBON 300 5% 1/4W
R1002 1-247-820-11 CARBON 360 5% 1/4W
R1003 1-249-414-11 CARBON 560 5% 1/4W F
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-11 CARBON 300 5% 1/4W
< SWITCH >
S1001 1-692-832-11 SWITCH, PUSH (1 KEY)(A PLAY)
S1002 1-692-832-11 SWITCH, PUSH (1 KEY)(B PLAY)
S1004 1-571-281-21 SWITCH, LEAF (A HALE)
S1005 1-571-281-21 SWITCH, LEAF (A CrO2)
S1006 1-572-248-11 SWITCH, LEAF (REC A)
S1007 1-572-248-11 SWITCH, LEAF (B HALE)
S1008 1-571-281-21 SWITCH, LEAF (B CrO2)
S1009 1-571-281-21 SWITCH, LEAF (REC B)
************************************************************
* A-4398-493-A MAIN BOARD, COMPLETE
*********************
< CAPACITOR >
C001 1-164-159-11 CERAMIC 0.1uF 50V
C128 1-162-306-11 CERAMIC 0.01uF 20% 16V
C129 1-126-933-11 ELECT 100uF 20% 10V
C131 1-164-159-11 CERAMIC 0.1uF 50V
C132 1-164-159-11 CERAMIC 0.1uF 50V
C134 1-164-159-11 CERAMIC 0.1uF 50V
C135 1-162-290-31 CERAMIC 470PF 10% 50V
C136 1-162-290-31 CERAMIC 470PF 10% 50V
C138 1-126-933-11 ELECT 100uF 20% 10V
C139 1-128-551-11 ELECT 22uF 20% 25V
C140 1-164-159-11 CERAMIC 0.1uF 50V
C402 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C403 1-162-290-31 CERAMIC 470PF 10% 50V
C405 1-126-301-11 ELECT 1uF 20% 50V
C406 1-137-399-11 FILM 0.1uF 5% 50V
C407 1-126-964-11 ELECT 10uF 20% 50V
C409 1-126-964-11 ELECT 10uF 20% 50V
C411 1-126-301-11 ELECT 1uF 20% 50V
C421 1-126-964-11 ELECT 10uF 20% 50V
C422 1-126-964-11 ELECT 10uF 20% 50V
C423 1-126-933-11 ELECT 100uF 20% 10V
C424 1-164-159-11 CERAMIC 0.1uF 50V
C425 1-164-159-11 CERAMIC 0.1uF 50V
C426 1-164-159-11 CERAMIC 0.1uF 50V
C427 1-126-935-11 ELECT 470uF 20% 16V
C428 1-126-933-11 ELECT 100uF 20% 16V
C429 1-126-933-11 ELECT 100uF 20% 10V
C452 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C453 1-162-290-31 CERAMIC 470PF 10% 50V
C455 1-126-301-11 ELECT 1uF 20% 50V
CD PANEL CONNECTOR LEAF SWITCH MAIN
To Next Page
