88 EQ-H/N O Equalizer H/N select output
89 BIAS O Bias ON/OFF signal output
90 REC-MUTE O Record mute ON/OFF selection output
91 NR-ON/OFF O Dolby noise reduction ON/OFF signal output
92 R/P-PASS I Record/playback/pass selection input
93 TC-MUTE O Tape mute ON/OFF selection output
94 A-PLAY-SW I Deck A play detect
95 B-PLAY-SW I Deck B play detect
96 RELAY O Record/playback head selection output for IC602
97 A-HALF I Deck A cassette detect
98 POWER O Power ON/OFF signal output
99 SW-F-CON O Super woofer mode signal output (Not used)
100 STK-MUTE O Power amp ON/OFF signal output
