7
Green: Locked to the REFERENCE input.
Red: Not locked to the REFERENCE input.
Not lit: No REFERENCE signal is input.
f RCP/MSU indicator
Displays the status when a remote control panel or master
setup unit is connected.
Lit: Indicates that an external control device (such as
MSU-1000 series Master Setup Unit or RCP-3000/1000
series Remote Control Panel) is connected.
Flashing: Indicates that an external control device is not
connected when using a network system connection.
Not lit: Indicates that an external control device is not
connected.
For details, see “Configuring Control System Connection
Settings” (page 10).
g USB connector (for connecting a USB drive)
Connect a USB drive to save or load the settings data file.
For details, see “Using a USB Drive” (page 50).
h CAMERA POWER switch and indicator
Turns the power ON/OFF.
ON: Set the switch to the ? position. The indicator lights green.
OFF: Set the switch to the 1 position.
i SDI 3/4 (serial digital interface) connectors (BNC-type)
For 3G-SDI or HD-SDI signal output.
For details about signal settings, see “Setting the Camera
Outputs” (page 10).
j REMOTE connector (round-type 8-pin)
Connect to external control device, such as the MSU-1000
series Master Setup Unit or RCP-3000/1000 series Remote
Control Panel.
When using a CCA-5 cable, it is recommended that you
connect an external power supply to the RCP if the supply
voltage to the unit is low or if connected over a long distance.
For details about external power supplies, contact your Sony
dealer.
k SDI 1/2 (serial digital interface) connectors (BNC-type)
For 12G-SDI, 6G-SDI, 3G-SDI, or HD-SDI signal output.
For details about signal settings, see “Setting the Camera
Outputs” (page 10).
l GL/SYNC (external sync signal input/sync signal
output) connector (BNC-type)
You can select whether to input an external sync reference
signal (BB or tri-level) to sync the camera, or output a sync
signal from the internal sync signal generator.
For details, see “MAINTENANCE menu” (page 26).
m DC IN (DC power supply input) connector (XLR 4-pin)
Connect to the AC-DN10A AC Adapter to supply power to the
camera.
n (LAN) connector (RJ-45 8-pin)
Used for LAN connection. Connect to a LAN hub (10BASE-T/
100BASE-TX) using a LAN cable (shielded type, category 5 or
higher).
• For safety, do not connect the connector for peripheral
device wiring that might have excessive voltage to this port.
Follow the instructions for this port.
• When you connect the LAN cable of the unit to peripheral
device, use a shielded-type cable to prevent malfunction
due to radiation noise.
o SDI MONI connector (BNC-type)
For HD-SDI signal output.
For details about signal settings, see “Setting the Camera
Outputs” (page 10).
Note
Notes
