44
<BLACK SHADING>
M03
V SAW R/G/B: –99 to +99, 0
R, G, and B values can be independently set.
M (master) value can also be set for BLACK.
V PARA R/G/B: –99 to +99, 0
H SAW R/G/B: –99 to +99, 0
H PARA R/G/B: –99 to +99, 0
BLK SET R/G/B: –99 to +99, 0
BLACK R/G/B/M: –99 to +99, 0
MASTER GAIN –6, –3, 0, 3, 6, 9, 12 dB
<OHB MATRIX>
M04
OHB MATRIX ON, OFF
MATRIX ON, OFF
<AUTO IRIS>
M05
AUTO IRIS ON, OFF, (ON), (OFF) Settings in ( ): When a remote control unit/panel or a
CCU is not connected (cannot be changed)
WINDOW 1
, 2, 3, 4, 5, 6 Selects the auto iris windows:
The shaded parts indicate the area where light
detection occurs.
OVERRIDE –99 to 99, 0
, --- Sets the override to temporarily change the
reference value for brightness of the automatic iris
level in the range of ±2 steps:
–99: Two steps to fully closed iris.
99: Two steps to fully opened iris.
--- : OFF
The setting returns to “ --- ” when the power is
turned off.
IRIS LEVEL –99 to +99, 0
±4 steps
APL RATIO –99 to +99, 65
IRIS GAIN –99 to +99, 0
IRIS CLOSE ON, OFF
<LENS1>
M06
F NO. DISP CONTROL, RETURN Selects the iris indication on the panel when AUTO
IRIS is off:
CONTROL: Displays the value from the camera
RETURN: Displays the value returned from the lens.
(When AUTO IRIS is on, the value returned from the
lens is always displayed.)
AF DISPLAY ON, OFF
ALAC AUTO, OFF With AUTO selected, the status is displayed at the
right.
(ACTIVE): Compensation is in progress.
(WAIT): Waiting for completion of lens initialization.
(STOP): Compensation is turned off for a non-
applicable lens.
F DROP COMP OFF
, ON, (OFF) Turns F drop compensation on/off.
During compensation, the compensation gain is
displayed on the right.
(OFF): For when a serial lens is not attached.
MAX GAIN 0.0
to 24 dB Maximum compensation value
DROP POINT 0 to 99, 50
Compensation start point
ROUNDNESS 0.0
to 12 dB Roundness of the compensation curve.
STORE LENS
FILE
Execute using ENTER. Saves settings to a lens file.
MAINTENANCE
Page title
Page No.
Item Settings Description
123
456
