45
<LENS2>
M07
REMOTE CONTROL OFF
, ON, (OFF) Lens remote control from MSU/RCP on/off setting.
Same function as the Active button on the Zoom/
Focus Control screen of the MSU/RCP.
(OFF): When lens is not supported
CONTROL
MODE
ZOOM&FOCUS
, FOCUS,
FOLLOW FOCUS
ZOOM & FOCUS: Control ZOOM and FOCUS from
an MSU/RCP (control by lens demand is not
supported)
FOCUS: Control FOCUS from an MSU/RCP. ZOOM
is controlled by lens demand.
FOLLOW FOCUS: FOCUS is controlled by lens
demand, but can be adjusted (offset fine
adjustment) from an MSU/RCP. ZOOM is
controlled by lens demand.
Note
Settings other than FOLLOW FOCUS cannot be
modified when the offset is not 0 and REMOTE
CONTROL is OFF. To change settings, set
REMOTE CONTROL to ON.
FOLLOW FOCUS
OFFSET ADJUST
SENS
1, 2, 3
, 4, 5 Sets the sensitivity of superimposing the offset of
the MSU.
OFFSET
CANCEL GAIN
1, 2, 3
, 4, 5 Sets the sensitivity of canceling the offset on the
demand side.
<MIC GAIN>
M08
MIC1 20, 30, 40, 50, 60
dB Can be modified only in standalone operation.
MIC2 20, 30, 40, 50, 60
dB
<CAMERA NUMBER>
M09
CAMERA NUMBER ---
, 1 to 96 Sets the camera number.
CCU LINK OFF
, ON Turns the link with the CCU No. on/off.
When on, you can set the camera number from the
CCU.
<CALL/TALLY>
M10
CCU CALL OFF, ON
Selects whether TALLY lights for CALL signal.
CAM CALL OFF
, ON
TALLY GUARD Selects whether to prevent changes while TALLY is
lit.
EXTENDER OFF
, ON
FILTER DISC OFF
, ON
<OUTPUT FORMAT>
M11 (U12)
CURRENT 1080: 59.94i, 50i
720: 59.94P, 50P
Displays the current format.
Only 1080:59.94P, 50P displayed when the
HDC3170 is connected to a CCU.
1080:59.94P, 50P are displayed in addition to the
settings on the left when the HDC3170 is operating
in standalone mode.
<TEST OUT>
M12 (U13)
OUTPUT SD-SYNC, HD-SYNC, VBS
VBS-OUT OUTPUT is displayed during VBS.
CHARACTER ON, OFF
GAIN –99 to +99, 0
CHROMA –99 to +99, 0
DOWN CONVERTER OUTPUT is displayed for VBS.
SELECT MAIN
, RET, VF
ASPECT SQ
, EC
SYNC-OUT OUTPUT is displayed during SD-SYNC and
HD-SYNC.
V-PHASE –999 to +999, 0
H-PHASE –999 to +999, 0
MAINTENANCE
Page title
Page No.
Item Settings Description
