Sony HDC5500 - Overview

3
Overview
The HDC5500/3500 is a color camera equipped with a newly developed 2/3 inch 4K CMOS sensor with global shutter for F10
(4K/59.94P)/F11 (4K/50P) high sensitivity and high signal-to-noise ratio.
Operation as a studio camera is supported when connected with a Camera Control Unit (CCU)
a)
using fiber cables.
Connection with other CCUs and wireless transmission are also supported by replacing the transmission adaptor side panel
of the unit with the following optional transmission adaptors.
HKC-FB50 UHB Fiber Transmission Adaptor
b) c)
Connects an HDCU5000/5500 Camera Control Unit to the unit to support UHB optical transmission.
HKC-TR37 Triax Transmission Adaptor
c)
Connects an HDCU3170 Camera Control Unit to the unit to support triax transmission.
HKC-WL50 Wireless Transmission Adaptor
b) c)
Connects to the unit to support wireless transmission of video signals and control signals.
HKC-FB30 Fiber Transmission Adaptor
c)
Connects an HDCU3500/3100 or HDCU2000-series Camera Control Unit to the unit to support optical transmission.
a)For details about camera control units that can be connected, see the system configuration diagrams (page 5) .
b)Use camera software version 2.00 or later.
c)The HKC-CN50 Side Panel Attachment Kit (option) is required in order to use the transmission adaptor.
Notes
• Before starting system operation, check that the software version and ROM version of the unit and system devices meet
the version requirements.
• For details about changing the transmission adaptor side panel, contact a Sony service or sales representative.
Supported Formats
The HDC3500 supports 1080-59.94i/50i and 720-59.94P/50P formats as standard. The HDC5500 also supports 1080-59.94P/
50P and HDR formats as standard.
(When an HKC-TR37 is installed in the HDC3500, 1080-59.94P/50P and HDR formats are supported as standard.)
You can extend the formats that are supported by installing the following camera operating software (option).
For details, contact a Sony service or sales representative.
Camera operating software
Extended formats HZC-DFR50 HZC-HFR50 HZC-PRV50 HZC-PSF50 HZC-UG50 HZC-UHD50
*1
1080-59.94P aa a
1080-50P aa a
1080-59.94i (×2) aa
1080-50i (×2) aa
1080-59.94P (×2) a
*2
a
*2
1080-59.94P (×3)/(×4) a
*2
1080-59.94P (×6)/(×8) a
*3
1080-50P (×2) a
*2
a
*2
1080-50P (×3)/(×4) a
*2
1080-50P (×6)/(×8) a
*3
1080-24PsF a
*4
1080-23.98PsF a
*4
1080-25PsF a
1080-29.97PsF a
720-59.94P (×2) aa
720-50P (×2) aa
4K-59.94P a
*5
a
*2
4K-50P a
*5
a
*2
