NETWORK SETTINGS menu
NETWORK SETTINGS
Page name
Page No.
Item Settings Description
<IP ADDR SET>
N01
HOST IP ADDRESS 0.0.0.0
to 255.255.255.255 Displays the IP address.
SUB NET MASK 0.0.0.0
to 255.255.255.254 Displays the subnet mask.
DEFAULT GATEWAY 0.0.0.0
to 255.255.255.255 Displays the default gateway.
SET A “SET OK?” message is displayed. Press ENTER
again to confirm the change. (Execute via ENTER.)
<LAN SETTINGS>
N02
AUTO NEGOTIATION ON
, OFF Selects whether to automatically set the connection
speed and communication system according to the
device connected.
AUTO MDIX ON
, OFF Sets the communication line.
CONNECT
CONFIGURATION
CONNECT
SPEED
10M, 100M
Selects the connection speed.
10M: 10BASE-TX
100M: 100BASE-TX
Available only when OFF is selected in AUTO
NEGOTIATION.
DUPLEX MODE HALF, FULL
Selects the communication system.
HALF: Half-duplex communication.
FULL: Full-duplex communication.
Available only when OFF is selected in AUTO
NEGOTIATION.
MDI/MDIX
SELECT
MDI
, MDIX Selects the communication line.
LINK CONDITION (DOWN), (UP) Displays connection status. (Display only)
(DOWN): Connection failure
(UP): Connection successful
SET A “SET OK?” message is displayed. Press ENTER
again to confirm the change. (Execute via ENTER.)
<CNS SETTINGS>
N03
CNS MODE LEGACY
, BRIDGE, MCS Sets the communication mode.
MCS MODE (CLIENT) Displays that the CCU is a CLIENT.
CCU NO blank, 1 to 96 Sets the CCU number.
MASTER IP ADDRESS 0.0.0.0
to 255.255.255.255 Sets the master device’s IP address for MCS mode.
<NETWORK RESET>
N04
ALL RESET A “NET SETTINGS RESET OK?” message is
displayed. Press ENTER again to reset NETWORK
SETTINGS menu items to factory default values.
(Execute via ENTER.)
