HKCU1003 (optional)
Design and specifications are subject to change without
notice.
General
Power supply 3.6 W
Operating temperature –10°C to +40°C (+14°F to 104°F)
Storage temperature –20°C to +60°C (–4°F to 140°F)
Dimensions (w/h/d) EN-B board: Approx. 19 × 110 × 226 mm
(3/4 × 4 3/8 × 8 7/8 inches)
VDA-A/B/C board: Approx. 19 × 98 × 159
mm (3/4 × 3 7/8 × 6 1/4 inches)
Mass EN-B board: Approx. 0.22 kg
VDA-A/B/C board: Approx. 0.10 kg
Output connectors
VDA-A board
VBS BNC-type (2), 1.0 Vp-p, 75 ohms, VBS
PIX OUT BNC-type (1), VBS/R/G/B (VBS 1.0 Vp-p,
75 ohms)
WF OUT BNC-type (1), VBS/R/G/B/SEQ (VBS
1.0 Vp-p, 75 ohms)
VDA-B board
FRAME REF IN BNC-type (1)
HD: SMPTE 274M, tri-level sync input,
0.6 Vp-p, 75 ohms
SD: Black burst input, 0.286 Vp-p, 75 ohms
FRAME REF OUT BNC-type (1)
Loop-through output or frame sync pulse
output, 0.3 Vp-p, 75 ohms, switchable
PIX OUT BNC-type (1), VBS/R/G/B (VBS 1.0 Vp-p,
75 ohms)
WF OUT BNC-type (1), VBS/R/G/B/SEQ (VBS
1.0 Vp-p, 75 ohms)
VDA-C board
VBS BNC-type (2), 1.0 Vp-p, 75 ohms, VBS
R/R-Y, G/Y, B/B-Y BNC-type (3)
• RGB video R/G/B (100% white):
0.7 Vp-p, 75 ohms
• Component video
Y (100% white): 0.714 Vp-p
R-Y/B-Y (75% color bar): 0.756 Vp-p,
75 ohms
Supplied accessories
4-pin connector (1)
Note
Always verify that the unit is operating properly before use.
SONY WILL NOT BE LIABLE FOR DAMAGES OF ANY
KIND INCLUDING, BUT NOT LIMITED TO,
COMPENSATION OR REIMBURSEMENT ON ACCOUNT
OF THE LOSS OF PRESENT OR PROSPECTIVE
PROFITS DUE TO FAILURE OF THIS UNIT, EITHER
DURING THE WARRANTY PERIOD OR AFTER
EXPIRATION OF THE WARRANTY, OR FOR ANY OTHER
REASON WHATSOEVER.
