Sony HDCU4300 - System Configuration

4
System Configuration
Production of some of the peripherals and related devices shown in the figures may have been discontinued.
For advice on choosing devices, please contact your Sony representative or dealer.
HDC4300 connection example
Note
Lens
(for ENG/EFP)
VCT-14
Tripod Attachment
Tr ip od
USB flash drive
Camera hanger
a)
HDVF-EL70
HDVF-700A
Viewfinder
CAC-6
Return Video Selector
Intercom Headset
Microphone
HDLA1500 series
Large Lens Adaptor
Lens
(for studio camera)
HDVF-EL75/L750/L770
Viewfinder
BKW-401
Viewfinder
HDC4300 Color Camera
CAC-6
Return Video Selector
Intercom Headset
CAC-12
Microphone
Holder
Microphone
HDC4300 Color
Camera
HDVF-20A
HDVF-200
HDVF-EL20
HDVF-EL30
Viewfinder
a) Supplied with HDLA1500 series (Part No.: A-1128-405-A)
b) Install NXLK-IP40F SDI-IP Converter Board (option).
c) Either an HKCU-IP43F or HKCU-4002 can be used.
d) Install HKCU-4002 12G-SDI Extension Kit (option).
e) Install HKCU-IP43F Networked Media Interface Board (option) for
communication with IP devices.
USB flash drive
CAC-6 Return Video
Selector
Intercom Headset
Microphone
BKP-7911
Script Holder
V-wedge shoe
(supplied with
tripod)
Tr ip od
HDCU4300
BNC
MSU-1000 series
Master Setup Unit
RCP-1000 series
Remote Control Panel
Video
Monitor
Waveform
Monitor
Video Router
CCA-5
LAN cable
Optical fiber cable
Hub
BNC×4
2K Video
Monitor
BNC
4K Video
Monitor
LAN cable
Sync signal input
Return video input
Intercom
Network Switch
Optical fiber cable
e)
PWS-100NM1
IP Live System Manager
Station
NXL-FR318
Signal Processing
Unit
b)
BNC×1
d)
or
< or
c)
m
