Sony HDCU5000 - Page 31

31
<VIDEO I/O>
S02
SDI-I/O 4 Sets SDI I/O 4.
I/O IN
, OUT Selects input or output.
SIGNAL When OUT is selected in I/O:
SDI-OUT
When IN is selected in I/O:
SDI-RET, HD PROMPTER
Sets the signal function.
UHD-SDI B Sets UHD-SDI B.
I/O OUT
Output (fixed)
SIGNAL SDI-OUT
, UHD TRUNK Sets the signal function.
UHD TRUNK is available on the HDCU5000/5500
only.
UHD-SDI C Sets UHD-SDI C.
I/O IN, OUT
Selects input or output.
SIGNAL When OUT is selected in I/O:
SDI-OUT
When IN is selected in I/O:
SDI-RET
Sets the signal function.
UHD-SDI D Sets UHD-SDI D.
I/O IN, OUT
Selects input or output.
SIGNAL When OUT is selected in I/O:
SDI-OUT
When IN is selected in I/O:
SDI-RET, UHD PROMPTER
Sets the signal function.
UHD PROMPTER is available on the HDCU5000/
5500 only.
UHD-SDI G Sets UHD-SDI G.
I/O IN, OUT
Selects input or output.
SIGNAL When OUT is selected in I/O:
SDI-OUT
When IN is selected in I/O:
SDI-RET
Sets the signal function.
UHD-SDI H Sets UHD-SDI H.
I/O IN, OUT
Selects input or output.
SIGNAL When OUT is selected in I/O:
SDI-OUT
When IN is selected in I/O:
SDI-RET
Sets the signal function.
SYSTEM CONFIG
Page name
Page No.
Item Set value Description
Note
Note
