32
<REAR I/F>
S03
CHARACTER CHARACTER
, AES/EBU, SYNC Sets the function to assign to the CHARACTER,
AES/EBU, SYNC connector.
CHARACTER: Set to VBS output on which
character superposition is performed.
AES/EBU: Set to AES/EBU output.
AES/EBU is available on the HDCU5500/3500 only.
SYNC: Set to SD composite sync or HD tri-level
reference sync signal output from the internal sync
signal generator.
PROMPTER2/
VBS-RET
ENABLE
Sets the function to assign to the PROMPTER2/
VBS-RET connector.
Set to ENABLE (fixed).
ENABLE: Set to both signal input for the second
tele-prompter and VBS return signal input.
MIC/WF REMOTE MIC REMOTE
, WF REMOTE Switches the function of pins 36 to 43 when a D-Sub
50-pin board is mounted as the INTERCOM/TALLY/
IO PORT connector.
REAR PREVIEW MOMENTARY
, TOGGLE Sets the operation mode of the REAR PREVIEW
connector output.
<GENLOCK>
S04
REFERENCE NOT DETECTED, EXT IN,
1080/59.94I, 1080/23.98PsF,
720/59.94P, 1080/50I,
1080/24PsF, 720/50P
Signal input of the REFERENCE IN connector
(Display only).
LOCK STATUS When HD or SD is selected in
GENLOCK MODE:
LOCKED, NOT LOCKED
Lock status of the external reference signal (Display
only).
GENLOCK MODE HD, SD
, NETWORK Sets the lock mode of the external reference signal.
• NETWORK is displayed only when the
HKCU-SFP50 ST 2110 Interface Kit is installed.
• Set to NETWORK if operating within an SMPTE
ST 2110 compliant system.
• When set to NETWORK, an external reference
input on the REFERENCE IN connector is not
required, and network synchronization operates
using the LAN 1 and LAN 2 connectors of the
HKCU-SFP50. The network synchronization
setting is configured on the <NETWORK
GENLOCK> page of the NETWORK menu.
10F BB OFF
, ON Sets whether to use the 10-field ID added to the
external reference signal
This can be selected when GENLOCK MODE is SD
and <MULTI FORMAT> page t SYSTEM is
1.001(525).
H-PHASE STEP When HD is selected in GENLOCK
MODE:
–3.01 to 3.45 µsec 0.00
When SD is selected in GENLOCK
MODE:
–8.29 to 9.48 µsec 0.00
Adjusts the horizontal lock phase in relation to the
reference signal (steps)
H-PHASE COARSE –99 to 99, 0
Adjusts the horizontal lock phase in relation to the
reference signal (fine adjustment)
V-PHASE 0
to 7 Adjusts the vertical lock phase in relation to the
reference signal (line)
SYNC OUT SELECT SD SYNC
, HD SYNC Sets the output signal of the REFERENCE OUT
connector.
SYSTEM CONFIG
Page name
Page No.
Item Set value Description
