<MULTI FORMAT>
S05
SYSTEM 1.001(525)
, 1.000(625) Selects the operating frequency of the system.
CAMERA FORMAT
When FIBER TRANSMIT RATE is
set to ULTRA and 1.001(525) is
selected in SYSTEM:
3840×2160/59.94P(2×),
3840×2160/59.94P,
3840×2160/29.97P,
3840×2160/23.98P,
1080/59.94P ,
1080/29.97PsF, 1080/23.98PsF,
1080/59.94I (RGB444),
1080/29.97PsF (RGB444),
1080/23.98PsF (RGB444),
1080/59.94P(2×), 1080/59.94P(3×),
1080/59.94P(4×), 1080/59.94P(6×),
1080/59.94P(8×)
When FIBER TRANSMIT RATE is
set to ULTRA and 1.000(625) is
selected in SYSTEM:
3840×2160/50P(2×),
3840×2160/50P, 3840×2160/25P,
3840×2160/24P, 1080/50P,
1080/25PsF, 1080/24PsF,
1080/50I (RGB444),
1080/25PsF (RGB444),
1080/24PsF (RGB444),
1080/50P(2×), 1080/50P(3×),
1080/50P(4×), 1080/50P(6×),
1080/50P(8×)
When FIBER TRANSMIT RATE is
set to HIGH and 1.001(525) is
selected in SYSTEM:
UHD/59.94P (4K/HDR),
1080/59.94P (4K/HDR),
1080/59.94P, 1080/59.94I
,
1080/29.97PsF, 1080/23.98PsF,
720/59.94P,
1080/59.94I (RGB444),
1080/29.97PsF (RGB444),
1080/23.98PsF (RGB444),
1080/59.94I(2×), 720/59.94P(2×)
When FIBER TRANSMIT RATE is
set to HIGH and 1.000(625) is
selected in SYSTEM:
UHD/50P (4K/HDR),
1080/50P (4K/HDR),
1080/50P, 1080/50I
, 1080/25PsF,
1080/24PsF, 720/50P,
1080/50I (RGB444),
1080/25PsF (RGB444),
1080/24PsF (RGB444),
1080/50I(2×), 720/50P(2×)
Selects the system format.
The formats available for selection vary depending
on the active format of the connected camera.
BIT DEPTH 10BIT, 12BIT Sets the RGB4:4:4 output bit length, and changes
the CCU output format.
This can be selected only when CAMERA FORMAT
is set to 1080/59.94I (RGB444), 1080/29.97PsF
(RGB444), 1080/23.98PsF (RGB444), 1080/50I
(RGB444), 1080/25PsF (RGB444), or 1080/24PsF
(RGB444).
SYSTEM CONFIG
Page name
Page No.
Item Set value Description
Note
