34
<MULTI FORMAT>
S05
CCU VIDEO
CONVERT
DISABLE
, ENABLE Sets the video converter function.
Set to ENABLE when CAMERA FORMAT is set to
the following.
When ENABLE is selected, set FRAME
SYNCHRONIZER to ON.
Tip: When CCU VIDEO CONVERT is set to
ENABLE, the video convert function within the CCU
introduces a delay, which is compensated for by
advancing the camera signal.
FRAME CONVERT
DELAY
0.8, 1.2, 1.6
[F@23.98PsF] Sets the video delay time for 2-3 Pulldown.
This is enabled only when SYSTEM is 1.001(525).
HD-SD DELAY LINE, FRAME
Sets the delay for SD signals down-converted from
HD signals.
90H, 120H, 1F
, 2F The delay duration display will be as follows when
CAMERA FORMAT is set to a 1080 format.
When LINE is selected: 90H
When FRAME is selected: 1F
The delay duration display will be as follows when
CAMERA FORMAT is set to a 720 format.
When LINE is selected: 120H
When FRAME is selected: 2F
SYSTEM CONFIG
Page name
Page No.
Item Set value Description
CAMERA FORMAT Conversion
output
3840×2160/59.94P(2×)
3840×2160/59.94P
UHD/59.94P(4K/HDR)
1080/59.94P(4K/HDR)
1080/59.94P
1080/59.94P(2×), (3×), (4×),
(6×), (8×)
720/59.94P
3840×2160/50P(2×)
3840×2160/50P
UHD/50P(4K/HDR)
1080/50P(4K/HDR)
1080/50P
1080/50P(2×), (3×), (4×),
(6×), (8×)
720/50P
