Sony HDCU5000 - Page 39

39
<OUTPUT FORMAT2>
S08
SDI-I/O3 Sets the output for the SDI I/O 3 connector.
MONITOR C Sets whether to add characters to the output signal.
C: Characters are not added.
This is fixed to C.
FORMAT FIBER TRANSMIT RATE is HIGH
and SYSTEM is 1.001(525): see
page 54
FIBER TRANSMIT RATE is HIGH
and SYSTEM is 1.000(625): see
page 56
FIBER TRANSMIT RATE is ULTRA
and SYSTEM is 1.001(525): see
page 58
FIBER TRANSMIT RATE is ULTRA
and SYSTEM is 1.000(625): see
page 62
Sets the output signal format of the SDI I/O 3
connector.
OETF SDR
, HDR OETF Sets the gamma curve of the video output.
COLOR BT709, BT2020 Selects the color space of SDI-I/O3 video output.
BT709: Sets the color output format to BT709.
BT2020: Sets the color output format to BT2020.
SDI-I/O4 Sets the output for the SDI I/O 4 connector.
MONITOR C Sets whether to add characters to the output signal.
C: Characters are not added.
This is fixed to C.
FORMAT FIBER TRANSMIT RATE is HIGH
and SYSTEM is 1.001(525): see
page 54
FIBER TRANSMIT RATE is HIGH
and SYSTEM is 1.000(625): see
page 56
FIBER TRANSMIT RATE is ULTRA
and SYSTEM is 1.001(525): see
page 58
FIBER TRANSMIT RATE is ULTRA
and SYSTEM is 1.000(625): see
page 62
Sets the output signal format of the SDI I/O 4
connector.
OETF SDR
, HDR OETF Sets the gamma curve of the video output.
COLOR BT709, BT2020 Selects the color space of SDI-I/O4 video output.
BT709: Sets the color output format to BT709.
BT2020: Sets the color output format to BT2020.
SYSTEM CONFIG
Page name
Page No.
Item Set value Description
Note
Note
