<OUTPUT FORMAT3>
S09
UHD-SDI A Sets the output of the UHD SDI A connector.
MONITOR C Sets whether to add characters to the output signal.
C: Characters are not added.
This is fixed to C.
FORMAT FIBER TRANSMIT RATE is HIGH
and SYSTEM is 1.001(525): see
page 54
FIBER TRANSMIT RATE is HIGH
and SYSTEM is 1.000(625): see
page 56
FIBER TRANSMIT RATE is ULTRA
and SYSTEM is 1.001(525): see
page 58
FIBER TRANSMIT RATE is ULTRA
and SYSTEM is 1.000(625): see
page 62
Sets the output signal format of the UHD SDI A
connector.
OETF SDR, 4K OETF Sets the gamma curve of the video output.
COLOR BT709, BT2020 Selects the color space of UHD-SDI A video output.
BT709: Sets the color output format to BT709.
BT2020: Sets the color output format to BT2020.
UHD-SDI B Sets the output of the UHD SDI B connector.
MONITOR C Sets whether to add characters to the output signal.
C: Characters are not added.
This is fixed to C.
FORMAT FIBER TRANSMIT RATE is HIGH
and SYSTEM is 1.001(525): see
page 54
FIBER TRANSMIT RATE is HIGH
and SYSTEM is 1.000(625): see
page 56
FIBER TRANSMIT RATE is ULTRA
and SYSTEM is 1.001(525): see
page 58
FIBER TRANSMIT RATE is ULTRA
and SYSTEM is 1.000(625): see
page 62
Sets the output signal format of the UHD SDI B
connector.
OETF SDR, 4K OETF Sets the gamma curve of the video output.
COLOR BT709, BT2020 Selects the color space of UHD-SDI B video output.
BT709: Sets the color output format to BT709.
BT2020: Sets the color output format to BT2020.
SYSTEM CONFIG
Page name
Page No.
Item Set value Description
Note
Note
