Sony HDCU5000 - Page 42

42
<OUTPUT FORMAT4>
S10
Displayed only when
HKCU-SDI50 is installed.
UHD-SDI E Sets the output of the UHD SDI E connector.
MONITOR C Sets whether to add characters to the output signal.
C: Characters are not added.
This is fixed to C.
FORMAT FIBER TRANSMIT RATE is HIGH
and SYSTEM is 1.001(525): see
page 54
FIBER TRANSMIT RATE is HIGH
and SYSTEM is 1.000(625): see
page 56
FIBER TRANSMIT RATE is ULTRA
and SYSTEM is 1.001(525): see
page 58
FIBER TRANSMIT RATE is ULTRA
and SYSTEM is 1.000(625): see
page 62
Sets the output signal format of the UHD SDI E
connector.
OETF SDR, 4K OETF Sets the gamma curve of the video output.
COLOR BT709, BT2020 Selects the color space of UHD-SDI E video output.
BT709: Sets the color output format to BT709.
BT2020: Sets the color output format to BT2020.
UHD-SDI F Sets the output of the UHD SDI F connector.
MONITOR C Sets whether to add characters to the output signal.
C: Characters are not added.
This is fixed to C.
FORMAT FIBER TRANSMIT RATE is HIGH
and SYSTEM is 1.001(525): see
page 54
FIBER TRANSMIT RATE is HIGH
and SYSTEM is 1.000(625): see
page 56
FIBER TRANSMIT RATE is ULTRA
and SYSTEM is 1.001(525): see
page 58
FIBER TRANSMIT RATE is ULTRA
and SYSTEM is 1.000(625): see
page 62
Sets the output signal format of the UHD SDI F
connector.
OETF SDR, 4K OETF Sets the gamma curve of the video output.
COLOR BT709, BT2020 Selects the color space of UHD-SDI F video output.
BT709: Sets the color output format to BT709.
BT2020: Sets the color output format to BT2020.
SYSTEM CONFIG
Page name
Page No.
Item Set value Description
Note
Note
