43
<OUTPUT FORMAT4>
S10
Displayed only when
HKCU-SDI50 is installed.
UHD-SDI G Sets the output of the UHD SDI G connector.
MONITOR C Sets whether to add characters to the output signal.
C: Characters are not added.
This is fixed to C.
FORMAT FIBER TRANSMIT RATE is HIGH
and SYSTEM is 1.001(525): see
page 54
FIBER TRANSMIT RATE is HIGH
and SYSTEM is 1.000(625): see
page 56
FIBER TRANSMIT RATE is ULTRA
and SYSTEM is 1.001(525): see
page 58
FIBER TRANSMIT RATE is ULTRA
and SYSTEM is 1.000(625): see
page 62
Sets the output signal format of the UHD SDI G
connector.
OETF SDR, 4K OETF Sets the gamma curve of the video output.
COLOR BT709, BT2020 Selects the color space of UHD-SDI G video output.
BT709: Sets the color output format to BT709.
BT2020: Sets the color output format to BT2020.
UHD-SDI H Sets the output of the UHD SDI H connector.
MONITOR C Sets whether to add characters to the output signal.
C: Characters are not added.
This is fixed to C.
FORMAT FIBER TRANSMIT RATE is HIGH
and SYSTEM is 1.001(525): see
page 54
FIBER TRANSMIT RATE is HIGH
and SYSTEM is 1.000(625): see
page 56
FIBER TRANSMIT RATE is ULTRA
and SYSTEM is 1.001(525): see
page 58
FIBER TRANSMIT RATE is ULTRA
and SYSTEM is 1.000(625): see
page 62
Sets the output signal format of the UHD SDI H
connector.
OETF SDR, 4K OETF Sets the gamma curve of the video output.
COLOR BT709, BT2020 Selects the color space of UHD-SDI H video output.
BT709: Sets the color output format to BT709.
BT2020: Sets the color output format to BT2020.
SYSTEM CONFIG
Page name
Page No.
Item Set value Description
Note
Note
