44
<OUTPUT FORMAT IP>
S11
Displayed only when
HKCU-SFP50 is installed.
IP-OUT1 Sets the output for the LAN 1 and LAN 2 connectors.
MONITOR C Sets whether to add characters to the output signal.
C: Characters are not added.
This is fixed to C.
FORMAT FIBER TRANSMIT RATE is HIGH
and SYSTEM is 1.001(525): see
page 54
FIBER TRANSMIT RATE is HIGH
and SYSTEM is 1.000(625): see
page 56
FIBER TRANSMIT RATE is ULTRA
and SYSTEM is 1.001(525): see
page 58
FIBER TRANSMIT RATE is ULTRA
and SYSTEM is 1.000(625): see
page 62
Sets the output signal format of the LAN 1 and LAN 2
connectors.
OETF SDR
, HDR OETF Sets the gamma curve of the video output.
COLOR BT709, BT2020 Selects the color space of IP-OUT1 video output.
BT709: Sets the color output format to BT709.
BT2020: Sets the color output format to BT2020.
SOURCE CAMERA Selects the signal source to output.
IP-OUT2 Sets the output for the LAN 1 and LAN 2 connectors.
MONITOR C
, M Sets whether to add characters to the output signal.
C: Characters are not added.
M: Characters are added.
FORMAT FIBER TRANSMIT RATE is HIGH
and SYSTEM is 1.001(525): see
page 54
FIBER TRANSMIT RATE is HIGH
and SYSTEM is 1.000(625): see
page 56
FIBER TRANSMIT RATE is ULTRA
and SYSTEM is 1.001(525): see
page 58
FIBER TRANSMIT RATE is ULTRA
and SYSTEM is 1.000(625): see
page 62
Sets the output signal format of the LAN 1 and LAN 2
connectors.
OETF SDR
, HDR OETF Sets the gamma curve of the video output.
COLOR BT709, BT2020 Selects the color space of IP-OUT2 video output.
BT709: Sets the color output format to BT709.
BT2020: Sets the color output format to BT2020.
SOURCE CAMERA Selects the signal source to output.
SYSTEM CONFIG
Page name
Page No.
Item Set value Description
Note
