<RETURN FORMAT2>
S14
SDI-I/O
1 1080/59.94P, 1080/50P,
1080/59.94I(PsF)
, 50I(PsF),
1080/23.98PsF, 24PsF,
720/59.94P, 50P, 525/59.94I(PsF),
625/50I(PsF)
Sets the format of the return signal to be input to the
SDI I/O connectors.
“DISABLED” is displayed if <VIDEO I/O> t
SDI-I/O 1, SDI-I/O 2, SDI-I/O 3, SDI-I/O 4 is set to
SDI-RET.
2
3
4
<RETURN FORMAT3>
S15
Displayed only for
HDCU5000/5500 or
HDCU3500 (with
HZCU-UHD35 installed).
UHD-SDI Sets the format of the return signal to be input to the
UHD SDI connectors.
• “DISABLED” is displayed if <VIDEO I/O> t
UHD-SDI C, UHD-SDI D is set to SDI-RET.
• UHD-SDI G and UHD-SDI H are displayed only
when HKCU-SDI50 is installed on the HDCU5000.
C 3840×2160/59.94P/12G
3840×2160/29.97P/6G
3840×2160/23.98P/6G
3840×2160/50P/12G
3840×2160/25P/6G
3840×2160/24P/6G
D
G
H
<RETURN FORMAT IP>
S16
Displayed only when
HKCU-SFP50 is installed.
IP-RET Sets the format of the return signal to be input on the
LAN 1 and LAN 2 connectors.
1IP-RET1,2
1080/59.94P, 1080/50P,
1080/59.94I
, 1080/50I
IP-RET3
1080/59.94I(PsF),
1080/50I(PsF)
IP-RET4
3840×2160/59.94P/12G,
3840×2160/50P/12G
2
3
4
