Sony HDCU5000 - Page 46

46
<RETURN SETUP>
S12
RETURN SELECT Sets the format of the return signal to be input.
For details on the selectable RETURN FORMAT
options for each SYSTEM (system operating
frequency) setting and CAMERA FORMAT (system
format) setting in <MULTI FORMAT>, see the
following.
FIBER TRANSMIT RATE is HIGH and SYSTEM is
1.001(525): page 54
FIBER TRANSMIT RATE is HIGH and SYSTEM is
1.000(625): page 56
FIBER TRANSMIT RATE is ULTRA and SYSTEM is
1.001(525): page 58
FIBER TRANSMIT RATE is ULTRA and SYSTEM is
1.000(625): page 62
• IP-RET1, IP-RET2, IP-RET3, IP-RET4 can be
selected on the HDCU5000/5500 when
HKCU-SFP50 is installed.
• IP-RET1, IP-RET2, IP-RET3 can be selected on
the HDCU3500 when HKCU-SFP50 is installed.
IP-RET4 can be selected when the HZCU-UHD35
option is enabled.
• UHD-SDI G and UHD-SDI H can be selected on
the HDCU5000 when HKCU-SDI50 is installed.
1 SDI-RET1
, SDI-RET2, SDI-RET3,
SDI-RET4, SDI-I/O1, SDI-I/O2,
SDI-I/O3, SDI-I/O4, UHD-SDI C,
UHD-SDI D, UHD-SDI G,
UHD-SDI H, VBS-RET, IP-RET1,
IP-RET2, IP-RET3, IP-RET4
2SDI-RET1, SDI-RET2
, SDI-RET3,
SDI-RET4, SDI-I/O1, SDI-I/O2,
SDI-I/O3, SDI-I/O4, UHD-SDI C,
UHD-SDI D, UHD-SDI G,
UHD-SDI H, VBS-RET, IP-RET1,
IP-RET2, IP-RET3, IP-RET4
3 SDI-RET1, SDI-RET2, SDI-RET3
,
SDI-RET4, SDI-I/O1, SDI-I/O2,
SDI-I/O3, SDI-I/O4, UHD-SDI C,
UHD-SDI D, UHD-SDI G,
UHD-SDI H, VBS-RET, IP-RET1,
IP-RET2, IP-RET3, IP-RET4
4 SDI-RET1, SDI-RET2, SDI-RET3,
SDI-RET4
, SDI-I/O1, SDI-I/O2,
SDI-I/O3, SDI-I/O4, UHD-SDI C,
UHD-SDI D, UHD-SDI G,
UHD-SDI H, VBS-RET, IP-RET1,
IP-RET2, IP-RET3, IP-RET4
5 SDI-RET1, SDI-RET2, SDI-RET3,
SDI-RET4, SDI-I/O1
, SDI-I/O2,
SDI-I/O3, SDI-I/O4, UHD-SDI C,
UHD-SDI D, UHD-SDI G,
UHD-SDI H, VBS-RET, IP-RET1,
IP-RET2, IP-RET3, IP-RET4
6 SDI-RET1, SDI-RET2, SDI-RET3,
SDI-RET4, SDI-I/O1, SDI-I/O2
,
SDI-I/O3, SDI-I/O4, UHD-SDI C,
UHD-SDI D, UHD-SDI G,
UHD-SDI H, VBS-RET, IP-RET1,
IP-RET2, IP-RET3, IP-RET4
7 SDI-RET1, SDI-RET2, SDI-RET3,
SDI-RET4, SDI-I/O1, SDI-I/O2,
SDI-I/O3
, SDI-I/O4, UHD-SDI C,
UHD-SDI D, UHD-SDI G,
UHD-SDI H, VBS-RET, IP-RET1,
IP-RET2, IP-RET3, IP-RET4
8 SDI-RET1, SDI-RET2, SDI-RET3,
SDI-RET4, SDI-I/O1, SDI-I/O2,
SDI-I/O3, SDI-I/O4
, UHD-SDI C,
UHD-SDI D, UHD-SDI G,
UHD-SDI H, VBS-RET, IP-RET1,
IP-RET2, IP-RET3, IP-RET4
FRAME
SYNCHRONIZER
OFF
, ON Sets the frame synchronizer function for the return
signal.
VBS ASPECT SQUEEZE, LETTER BOX, EDGE
CROP
Sets the aspect ratio of the VBS input signal.
<RETURN FORMAT1>
S13
SDI-RET
1 1080/59.94P/3G, 1080/50P/3G
1080/59.94I(PsF)
, 50I(PsF),
1080/23.98PsF, 24PsF,
720/59.94P, 50P, 525/59.94I(PsF),
625/50I(PsF)
Sets the format of the return signal to be input to the
SDI RET connectors.
When an SD signal is set (525 or 625), set the
aspect ratio of the input signal.
SQUEEZE, LETTER BOX, EDGE CROP
2
3
4
SYSTEM CONFIG
Page name
Page No.
Item Set value Description
Notes
