<WEB MENU>
N03
WEB MENU ENABLE
, DISABLE Enables/disables the web menu.
PORT LAN-COM
Selects the connection port.
SERVICE
DISCOVERY
ON
, OFF Enables/disables the service discovery function.
ON: Display the CCU list in the web menu.
OFF: Do not display the CCU list in the web menu.
• Set this to OFF if the CCU list is not required or
when you want to reduce the network load as
much as possible.
• When set to OFF, the unit cannot be detected by
the service discovery from other CCUs on the
same subnet.
<NETWORK GENLOCK>
N04
Displayed only when
HKCU-SFP50 is installed.
PORT LAN1, LAN2 Selects the port to use.
NETWORK
GENLOCK
DISABLE, ENABLE
Enables/disables network genlock.
PROFILE ST2059-2 Displays the supported profile.
Only the ST2059-2 profile is supported.
DOMAIN
NUMBER
0 to 127, 127
Sets the domain number.
Set to the domain number of the master device to be
connected.
COMMUNICATION
MODE
MULTICAST MODE, MIXED
MODE
MIXED MODE: Unicast reply to the master.
MULTICAST MODE: Multicast reply to the master.
DELAY
REQUEST
INTERVAL
–7 to –1, –3
Displays the delay of the response to the PTP
master.
PTP MASTER INFO Displays information obtained from the PTP master.
IP ADDRESS 0.0.0.0 to 255.255.255.255 Displays the IP address of the currently
synchronized PTP master device.
SYNC INTERVAL –7 to –1, –3
Displays the Sync Interval setting of the master
device.
PRIORITY 1 0 to 255, 128
Displays the priority level of the PTP master.
The lower the number, the higher the priority.
PRIORITY 2 0 to 255, 128
STEP ONE-STEP, TWO-STEP Displays the mode in which the timestamp is sent.
ONE-STEP: Sent in Sync message.
TWO-STEP: Sent in Follow-up message.
LOCK STATUS NOT IN USE
, NO MASTER,
LOCKING, LOCKED
Displays the genlock operation status.
NOT IN USE: PTP operation stopped
NO MASTER: PTP master not found
LOCKING: Synchronizing
LOCKED: Synchronized
