<PTP STATUS>
N05
Displayed only when
HKCU-SFP50 is installed.
PTP NIC LAN1, LAN2 Displays the port on which PTP is running.
STATUS NO MASTER, LOCKED,
LOCKING, NOT IN USE
Displays the PTP status.
NOT IN USE: PTP operation stopped
NO MASTER: PTP master not found
LOCKING: Synchronizing
LOCKED: Synchronized
PORT LAN1, LAN2 Selects the port for which to display the status.
UTC Time 1970-01-01 00:00:00 Master time (displays the internal time when the
master is Free-run or Disable).
MasterID 0000000000000000-0 Displays the master clock ID.
GMClockID 0000000000000000-0 Displays the grandmaster clock ID.
Sync 0Hz (0pkts) Displays the sync message rate.
FollowUp 0Hz (0pkts) Displays the follow-up message rate.
DelayReq 0Hz (0pkts) Displays the delay request message rate.
DelayResp 0Hz (0pkts) Displays the delay response message rate.
Network Status UNAVAILABLE, NOT GOOD,
GOOD, VERY GOOD
Displays the network status.
Delay 0ns Displays the network delay.
Jitter 0ns Displays the network jitter.
<IP LIVE>
N06
Displayed only when
HKCU-SFP50 is installed.
IP LIVE SYSTEM MANAGER
PORT DISABLE, LAN1&LAN2
Sets the IP Live System Manager (LSM).
DISABLE: Does not communicate with LSM.
LAN1&LAN2: Communicates with LSM using LAN1
and LAN2 (for redundancy).
Restart the unit after changing the PORT setting.
DHCP OFF
Sets the IP address of the LSM (fixed OFF).
PRIMARY IP
ADDRESS
0.0.0.0
to 255.255.255.255 Sets the IP address of LSM1.
SECONDARY IP
ADDRESS
0.0.0.0
to 255.255.255.255 Sets the IP address of LSM2.
PRIMARY
CONNECTION
STATUS
DISCONNECTED
, CONNECTING,
CONNECTED
Displays the status of the connection with LSM1.
DISCONNECTED: Disconnected.
CONNECTING: Establishing communication.
CONNECTED: Communication established.
SECONDARY
CONNECTION
STATUS
DISCONNECTED
, CONNECTING,
CONNECTED
Displays the status of the connection with LSM2.
DISCONNECTED: Disconnected.
CONNECTING: Establishing communication.
CONNECTED: Communication established.
MULTICAST
ADDRESS
AUTO
, MANUAL Sets the mode switching method for the multicast
address setting of IP stream.
Fixed to AUTO when PORT is set to LAN1&LAN2,
and uses multicast addresses configured from the
LSM.
Fixed to MANUAL when PORT is set to DISABLE,
and uses the addresses set manually using the
MULTICAST ADDRESS 1 to 5 pages.
HITLESS FAILOVER ON
, OFF Enables/disables IP stream redundancy.
NETWORK
Page name
Page No.
Item Set value Description
Note
