78
<NMOS>
N07
Displayed only when
HKCU-SFP50 is installed.
PORT DISABLE
, LAN-COM Selects the ports on which NMOS is enabled.
Can be selected only when <IP LIVE> t IP LIVE
SYSTEM MANAGER t PORT is set to DISABLE.
PORT NUMBER
(IS-04 NODE)
100 to 65535, 3001
Sets the port number for the IS-04 Node API.
PORT NUMBER
(IS-05
CONNECTION)
100 to 65535, 3002
Sets the port number for the IS-05 Connection API.
RDS DISCOVERY ON
, OFF Enables/disables auto detection using the
Registration & Discovery System (RDS).
When enabled, RDS discovery is enabled within the
same subnet.
If RDS is not available on the same subnet, disable
the setting and set the IP address manually.
RDS CONNECTION
STATUS
DISCONNECTED
,
CONNECTING,
CONNECTED
Displays the RDS connection status.
RDS IP ADDRESS 0.0.0.0
to 255.255.255.255 Displays the detected RDS IP address when RDS
DISCOVERY is set to ON.
Sets the RDS IP address manually when RDS
DISCOVERY is set to OFF.
RDS PORT NUMBER 100 to 65535, 18235
Displays the detected RDS port when RDS
DISCOVERY is set to ON.
Sets the RDS port manually when RDS
DISCOVERY is set to OFF.
<MULTICAST ADDRESS
1>
N08
Displayed only when
HKCU-SFP50 is installed.
MULTICAST
ADDRESS
AUTO
, MANUAL Displays the mode of the multicast address setting of
the IP stream.
VIDEO OUT LAN1-1
Displayed on the HDCU3500 only when the
HZCU-UHD35 option is enabled.
IP ADDRESS 224.0.0.1 to 239.255.255.255 Displays the destination IP address.
PORT 100 to 65535
Displays the transmit destination port number.
VIDEO OUT LAN1-2 Same setting items and values as VIDEO OUT
LAN1-1.
VIDEO OUT LAN1-3 Same setting items and values as VIDEO OUT
LAN1-1.
VIDEO OUT LAN1-4 Same setting items and values as VIDEO OUT
LAN1-1.
VIDEO OUT LAN2-1 Same setting items and values as VIDEO OUT
LAN1-1.
VIDEO OUT LAN2-2 Same setting items and values as VIDEO OUT
LAN1-1.
VIDEO OUT LAN2-3 Same setting items and values as VIDEO OUT
LAN1-1.
VIDEO OUT LAN2-4 Same setting items and values as VIDEO OUT
LAN1-1.
Displayed on the HDCU3500 only when the
HZCU-UHD35 option is enabled.
NETWORK
Page name
Page No.
Item Set value Description
