Sony HDCU5000 - Page 79

79
<MULTICAST ADDRESS
2-1>
N09
Displayed only when
HKCU-SFP50 is installed.
MULTICAST
ADDRESS
AUTO, MANUAL Displays the MULTICAST ADDRESS setting of the
<MULTICAST SETTING> page.
RETURN LAN1-1
Displayed on the HDCU3500 only when the
HZCU-UHD35 option is enabled.
IP ADDRESS 224.0.0.1 to 239.255.255.255 Displays the receive destination IP address.
PORT 100 to 65535
Displays the receive destination port number.
SRC IP 0.0.0.0
to 255.255.255.255 Displays the stream transmit source IP address.
RETURN LAN1-2 Same setting items and values as RETURN LAN1-1.
RETURN LAN1-3 Same setting items and values as RETURN LAN1-1.
RETURN LAN1-4 Same setting items and values as RETURN LAN1-1.
Displayed on the HDCU3500 only when the
HZCU-UHD35 option is enabled.
<MULTICAST ADDRESS
2-2>
N09
Displayed only when
HKCU-SFP50 is installed.
MULTICAST
ADDRESS
AUTO
, MANUAL Displays the MULTICAST ADDRESS setting of the
<MULTICAST SETTING> page.
RETURN LAN2-1
IP ADDRESS 224.0.0.1 to 239.255.255.255 Displays the receive destination IP address.
PORT 100 to 65535
Displays the receive destination port number.
RETURN LAN2-2 Same setting items and values as RETURN LAN2-1.
RETURN LAN2-3 Same setting items and values as RETURN LAN2-1.
RETURN LAN2-4 Same setting items and values as RETURN LAN2-1.
<MULTICAST ADDRESS
3>
N10
Displayed only when
HKCU-SFP50 is installed.
MULTICAST
ADDRESS
AUTO, MANUAL Displays the MULTICAST ADDRESS setting of the
<MULTICAST SETTING> page.
AUDIO OUT LAN1
IP ADDRESS 224.0.0.1 to 239.255.255.255 Displays the transmit destination IP address.
PORT 100 to 65535
Displays the transmit destination port number.
AUDIO OUT LAN2 Same setting items and values as AUDIO OUT
LAN1.
HD TRUNK AUDIO
OUT LAN1
Same setting items and values as AUDIO OUT
LAN1.
HD TRUNK AUDIO
OUT LAN2
Same setting items and values as AUDIO OUT
LAN1.
PGM IN LAN1
IP ADDRESS 224.0.0.1 to 239.255.255.255 Displays the receive destination IP address.
PORT 100 to 65535
Displays the receive destination port number.
SRC IP 0.0.0.0
to 255.255.255.255 Displays the stream transmit source IP address.
PGM IN LAN2 Same setting items and values as PGM IN LAN1.
<MULTICAST ADDRESS
4>
N11
Displayed only when
HKCU-SFP50 is installed.
MULTICAST
ADDRESS
AUTO, MANUAL Displays the MULTICAST ADDRESS setting of the
<MULTICAST SETTING> page.
INTERCOM OUT
LAN1
IP ADDRESS 224.0.0.1 to 239.255.255.255 Displays the transmit destination IP address.
PORT 100 to 65535
Displays the transmit destination port number.
INTERCOM OUT
LAN2
Same setting items and values as INTERCOM OUT
LAN1.
INTERCOM IN LAN1
IP ADDRESS 224.0.0.1 to 239.255.255.255 Displays the receive destination IP address.
PORT 100 to 65535
Displays the receive destination port number.
SRC IP 0.0.0.0
to 255.255.255.255 Displays the stream transmit source IP address.
INTERCOM IN LAN2 Same setting items and values as INTERCOM IN
LAN1.
NETWORK
Page name
Page No.
Item Set value Description
Note
Note
