80
<MULTICAST ADDRESS
5>
N12
Displayed only when
HKCU-SFP50 is installed.
MULTICAST
ADDRESS
AUTO
, MANUAL Displays the MULTICAST ADDRESS setting of the
<MULTICAST SETTING> page.
META OUT LAN1-1
IP ADDRESS 224.0.0.1 to 239.255.255.255 Displays the transmit destination IP address.
PORT 100 to 65535
Displays the transmit destination port number.
META OUT LAN1-2 Same setting items and values as META OUT
LAN1-1.
META OUT LAN1-3 Same setting items and values as META OUT
LAN1-1.
META OUT LAN2-1 Same setting items and values as META OUT
LAN1-1.
META OUT LAN2-2 Same setting items and values as META OUT
LAN1-1.
META OUT LAN2-3 Same setting items and values as META OUT
LAN1-1.
<EMBER+>
N13
EMBER+ DISABLE
, ENABLE Enables/disables configuration using Ember+.
Can be enabled by installing HZCU-CNFG50 Config
Control Software (option).
PORT LAN-COM
Displays the connection port name.
PORT NUMBER 9000
Displays the TCP port number for the Ember+
connection.
CONNECTION
STATUS
DISCONNECTED
, CONNECTING,
CONNECTED
Displays the connection status of Ember+
communication.
DISCONNECTED: Disconnected.
CONNECTING: Establishing communication.
CONNECTED: Communication established.
<TSL UMD>
N14
TSL UMD DISABLE
, ENABLE Enables/disables IP Tally using TSL UMD V5.0.
PORT LAN-COM
Displays the connection port name.
PORT NUMBER 8900
Displays the UDP port number of the TSL UMD
connection.
PACKET STATUS NOT RECEIVED
, RECEIVED Displays the TSL UMD packet reception status.
When received, it also displays IDs and the on/off status
of the red, green, and yellow tallies.
Up to five IDs can be displayed. “AND MORE” is
displayed if there are more.
NETWORK
Page name
Page No.
Item Set value Description
