25
GB
Additional Information
Specifications
Formats supported by this system
Digital input formats supported by
this system are as follows.
Sound Bar
Amplifier section
POWER OUTPUT (rated)
Front L + Front R: 7 W + 7 W
(at 4 ohms, 1 kHz, 1 % THD)
POWER OUTPUT (reference)
Front L/Front R: 15 W
(per channel at 4 ohms, 1 kHz)
Inputs
ANALOG
OPTICAL
COAXIAL
BLUETOOTH section
Communication system
BLUETOOTH Specification
version 2.1 +
EDR (Enhanced Data Rate)
Output
BLUETOOTH Specification Power
Class 2
Maximum communication range
Line of sight approx. 10 m
*1
Frequency band
2.4 GHz band (2.4000 GHz -
2.4835 GHz)
Modulation method
FHSS (Freq Hopping Spread
Spectrum)
Compatible BLUETOOTH profiles
*2
A2DP (Advanced Audio Distribution
Profile)
Supported Codecs
*3
SBC
*4
Transmission range (A2DP)
20 Hz - 20,000 Hz (Sampling
frequency 44.1 kHz)
*1
The actual range will vary depending
on factors such as obstacles between
devices, magnetic fields around a
microwave oven, static electricity,
cordless phone, reception sensitivity,
operating system, software
application, etc.
*2
BLUETOOTH standard profiles
indicate the purpose of BLUETOOTH
communication between devices.
*3
Codec: Audio signal compression
and conversion format
*4
Subband Codec
Front speaker unit
Speaker system
2-way speaker system, Acoustic
Suspension
Speaker unit
Woofer: 25 mm × 120 mm
Tweeter: 38 mm
cone type
Rated impedance
4ohms
Power requirements
220 V - 240 V AC, 50/60 Hz
Power consumption
On: 20 W
Standby mode: 0.5 W or less
Dimensions (approx.)
940 mm × 83 mm × 70 mm (with
stands)
940 mm × 71 mm × 69 mm (without
stands)
Mass (approx.)
1.7 kg
Subwoofer
POWER OUTPUT (reference)
30 W (per channel at 8 ohms,
100 Hz)
Speaker system
Subwoofer, Bass reflex
Speaker unit
130 mm cone type
Rated impedance
8ohms
Format Supported/Not
supported
Dolby Digital
Linear PCM 2ch 48 kHz
or less
