A SW: Lights up when the audio signal is output
from the SUB WOOFER jack.
B LFE: Lights up when the disc being played
back contains the LFE (Low Frequency
Effect) channel and the LFE channel signal is
actually being reproduced.
C SP A/SP B: Lights up in accordance with the
speaker system being used (A or B). Turns off
when speaker output is turned off or when
headphones are connected.
D ; DIGITAL EX: “; DIGITAL” lights up
when Dolby Digital signals are input.
“; DIGITAL EX” lights up when Dolby
Digital EX signals are input.
Note
When playing a Dolby Digital format disc, be
sure that you have made digital connections and
that INPUT MODE is not set to “ANALOG”
(page 33).
E ; PRO LOGIC IIx: “; PRO LOGIC”
lights up when the receiver applies Pro Logic
processing to 2 channel signals in order to
output the center and surround channel
signals. “; PRO LOGIC II” lights up when
the Pro Logic II Movie/Music/Game decoder
is activated. “; PRO LOGIC IIx” lights up
when the Pro Logic IIx Movie/Music/Game
decoder is activated.
Note
Dolby Pro Logic IIx decoding does not function
for DTS format signals or for signals with a
sampling frequency of more than 48 kHz.
F DTS-ES 96/24: “DTS” lights up when DTS
signals are input. “DTS-ES” lights up when
DTS-ES signals are input. “DTS 96/24” lights
up when the receiver is decoding DTS 96 kHz/
24 bit signals.
Note
When playing a DTS format disc, be sure that you
have made digital connections and that INPUT
MODE is not set to “ANALOG” (page 33).
G NEO:6: Lights up when DTS Neo:6 Cinema/
Music mode decoding is activated.
H Tuner indicators: Lights up when using the
receiver to tune in radio stations, etc. See
pages 22–24 for tuner operations.
I D.RANGE: Lights up when dynamic range
compression is activated (page 34).
J COAX: Lights up when the source signal is a
digital signal being input through the
COAXIAL terminal or when INPUT MODE
is set to “COAX IN”
(page 33).
K OPT: Lights up when the source signal is a
digital signal being input through the
OPTICAL terminal or when INPUT MODE is
set to “OPT IN”
(page 33).
L SLEEP: Lights up when sleep timer is
activated.
About the indications in the display
L C R
SL
SB
SSR
LFE
SP A
DIGITAL EX
PRO LOGIC IIx
DTS-ES NEO:6
D.RANGE
SLEEP OPT COAX
96/24
SP B
;;
SW
MEMORY
STEREO MONO
9 8
