HT-RT3
11
2-4. CHASSIS SECTION
2-5. BLUETOOTH MODULE
1 six screws (+BV TAPPING SCREW TYPE-1 3.5)
2 panel, rear (EL-SW)
3 Draw out chassis section in
the arrow direction.
4 chassis section
– Rear view –
5 holder, BT
2 one screw (+BVTP 3 x 8)
3 BLUETOOTH module
4 two screws (+BVTP 3 x 8)
1 wire (flat type) (18 core)
– Rear view –

Sony HT-RT3 Specifications

General

Disc types supported	No
Optical disc player type	Not included
Multichannel decoding	Yes
Card reader integrated	-
Audio decoders	Dolby Digital, Dolby Dual Mono
RMS rated power	600 W
Audio output channels	5.1 channels
Audio formats supported	LPCM, PCM
Product color	Black
Cables included	Optical
Subwoofer type	Active subwoofer
Digital audio optical out	1
Power consumption (typical)	85 W

Weight and Dimensions

Main unit weight	2100 g
Subwoofer weight	7800 g
