Sony HT-RT3 Service Manual

HT-RT3
12
2-6. SPEAKER CHUKEI PC BOAR BOARD
2 Remove chassis,
top (EL-SW) in the
direction of arrow.
4 chassis, top (EL-SW)
6 two screws
(+BV3 (3-CR))
7 one screw (+BVTP 3 x 8)
5 CN1002 (12P)
1 seven screws (+BVTP 3 x 8)
8 SPEAKER CHUKEI PC
BOAR board
:LUHVHWWLQJ
3 Draw out wire (flat type) (18 core) from
chassis, top (EL-SW).
–5HDUYLHZ–
rear side
wire (flat type) (18 core)
top side

Sony HT-RT3 Specifications

General

Disc types supported	No
Optical disc player type	Not included
Multichannel decoding	Yes
Card reader integrated	-
Audio decoders	Dolby Digital, Dolby Dual Mono
RMS rated power	600 W
Audio output channels	5.1 channels
Audio formats supported	LPCM, PCM
Product color	Black
Cables included	Optical
Subwoofer type	Active subwoofer
Digital audio optical out	1
Power consumption (typical)	85 W

Weight and Dimensions

Main unit weight	2100 g
Subwoofer weight	7800 g
