Sony HXC-FB80 - Page 59

59
<AUDIO>
M07 (U14)
AUDIO1 LINE(0dB), 20dB, 30dB, 40dB,
50dB, 60dB
( ) display: Displayed when not in standalone operation mode,
or in standalone operation mode when <VR ASSIGN> is set
to MIC (MIC GAIN1, MIC GAIN2, MIC GAIN1+2) (not
configurable)
AUDIO2
TEST TONE ON, OFF
<CALL/TALLY>
M08
CCU CALL ON, OFF, --- ---: When a CCU is not connected
CAM CALL ON, OFF
, ---
<OUTPUT FORMAT>
M09 (U15)
CURRENT Displays the current format.
In standalone operation mode, the format and region are
configurable (restart required).
NTSC AREA or NTSC(J) AREA:
1080: 59.94i, 59.94P, 29.97PsF, 23.98PsF, 59.94i HDR, 59.94P
HDR
720: 59.94P
PAL AREA:
1080: 50i, 50P, 25PsF, 50i HDR, 50P HDR
720: 50P
COUNTRY NTSC AREA, PAL AREA,
NTSC(J) AREA
<TEST OUT>
M10 (U16)
OUTPUT SD-SYNC, HD-SYNC, VF
, VBS VBS is not displayed in HDR mode
SYNC-OUT Displayed when OUTPUT is SD-SYNC or HD-SYNC
V-P HA SE −999 to 999 0
H-PHASE −999 to 999 0
VBS-OUT Displayed when OUTPUT is VBS
CHARACTE
R
ON, OFF
GAIN −99 to 99 0
CHROMA −99 to 99 0
SETUP ON, OFF Displayed when COUNTRY in <OUTPUT FORMAT> is set to
NTSC AREA or NTSC(J) AREA
DOWN
CONVERTER
Displayed when OUTPUT is VBS
SELECT MAIN
, RET, VF
ASPECT SQ
, EC
MAINTENANCE
Page name
Page No.
Item Setting Description / Remarks
