Sony ICD-P320 - 2 Disassembly; Case (Front) Assy

4
ICD-P320
Note : Follow the disassembly procedure in the numerical order given.
2-1. CASE (FRONT) ASSY
SECTION 2
DISASSEMBLY
Note : Disassemble the unit in the order as shown below.
2-1. CASE (FRONT) ASSY
(Page 4)
2-2. MAIN BOARD
(Page 5)
SET
2-3. USB BOARD
(Page 5)
8
2 screw
9 two screws
0 two brackets (speaker)
qa speaker
qs case (front) assy
3 claw
4 claw
6 claw
7 claw
5 two claws
1 battery case lid
