– 21 –
SECTION 6
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
ALARM KEY
ANTENNA MAIN
* 1-671-841-11 ALARM KEY BOARD
****************
< SWITCH >
S201 1-553-856-00 SWITCH, KEY BOARD (–, ALARM TIME (B))
S202 1-553-856-00 SWITCH, KEY BOARD (+, ALARM TIME (A))
S203 1-553-856-00 SWITCH, KEY BOARD (B, ON/OFF)
S204 1-553-856-00 SWITCH, KEY BOARD (–, ALARM TIME (A))
S205 1-553-856-00 SWITCH, KEY BOARD (+, ALARM TIME (A))
S206 1-553-856-00 SWITCH, KEY BOARD (A, ON/OFF)
**************************************************************
A-3683-116-A ANTENNA BOARD, COMPLETE
************************
< CAPACITOR >
C451 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C454 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C455 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C456 1-163-989-11 CERAMIC CHIP 0.033uF 10% 25V
C457 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C459 1-136-682-11 FILM 0.0039uF 5% 100V
< IC >
IC451 8-759-599-59 IC U4226B-MFSG3
< RESISTOR >
R453 1-216-295-00 SHORT 0
R456 1-216-295-00 SHORT 0
R458 1-216-295-00 SHORT 0
R459 1-216-295-00 SHORT 0
R460 1-216-097-00 RES, CHIP 100K 5% 1/10W
R461 1-216-121-00 RES, CHIP 1M 5% 1/10W
< FILTER >
X451 1-767-219-11 FILTER, CRYSTAL (77.5kHz)
**************************************************************
A-3663-389-A MAIN BOARD, COMPLETE
*********************
3-032-464-01 HOLDER (LCD)
3-033-972-01 HOLDER, FERRITE-ROD ANTENNA
7-685-649-79 SCREW +P 3X14 TYPE2 NON-SLIT
< BAND-PASS FILTER >
BPF1 1-236-711-21 FILTER, BAND PASS
< CAPACITOR >
C6 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C7 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C8 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C9 1-163-224-11 CERAMIC CHIP 7PF 0.25PF 50V
C11 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C20 1-163-059-00 CERAMIC CHIP 0.01uF 10% 50V
C21 1-126-963-11 ELECT 4.7uF 20% 50V
C22 1-126-964-11 ELECT 10uF 20% 50V
C23 1-163-063-11 CERAMIC CHIP 0.022uF 10% 50V
C24 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C26 1-126-964-11 ELECT 10uF 20% 50V
C27 1-163-085-00 CERAMIC CHIP 2PF 50V
C28 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C29 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C30 1-126-960-11 ELECT 1uF 20% 50V
C31 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C32 1-163-131-00 CERAMIC CHIP 390PF 5% 50V
C33 1-163-989-11 CERAMIC CHIP 0.033uF 10% 25V
C34 1-163-237-11 CERAMIC CHIP 27PF 5% 50V
C41 1-126-934-11 ELECT 220uF 20% 10V
C42 1-128-551-11 ELECT 22uF 20% 25V
C43 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C44 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C45 1-126-934-11 ELECT 220uF 20% 10V
C47 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C48 1-163-077-00 CERAMIC CHIP 0.1uF 10% 25V
C50 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C51 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C53 1-110-501-11 CERAMIC CHIP 0.33uF 10% 16V
C54 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
C55 1-126-935-11 ELECT 470uF 20% 6.3V
C57 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C59 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C60 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C62 1-126-934-11 ELECT 220uF 20% 10V
C63 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
C66 1-107-812-11 TANTALUM CHIP 4.7uF 20% 6.3V
C100 1-163-038-00 CERAMIC CHIP 0.1uF 25V
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
